2400 – 2483 MHz Directional Wall Mount Flat Patch Panel Antenna
AMXW-2400-12
2.4G/12dBi panel Antenna
The wall mount antennas have excellent features such as beautiful appearance, high gain, anti-jamming ability,low VSWR. It can be applied to buildings, elevators, streets, parking and many other occasions. The Wall mount antenna housings with PVC material injection molding, can effectively prevent the antenna from acid rain, oxidation, alkali, salt spray and other corrosion in the harsh environment ,to ensure long-term use indoor and outdoor.
Specification:
2.4G WiFi/WiMAx outdoor patch panel antenna
2.4 GHz ISM band,
2.4 GHz spread spectrum communication system,
WiFi,WIMAX
Feature:
High gain, strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
2.4 GHz WLAN system
2.4 GHz ISM frequency band
Wi-Fi system
|
AMXW-2400-12 Electrical Specifications | |
Frequency range(MHz) |
2400-2483 |
Band width(MHz) |
83 |
Gain(dBi) |
12 |
Half-power beam width(°) |
H:50 V:30 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
RP-SMA Male or Requested |
Mechanical Specifications | |
Dimensions-mm (Height/Width/Depth) |
198*98*25 |
Antenna weight(kg) |
0.4 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome material |
ABS |
Radome color |
white |
Waterproof Standard |
IP54/ IP65/ IP67 |
Mounting way |
wall-hanging or pole-holding |
Mounting hardware(mm)) |
35-50 |
Welcome to Ameison Communication Equipment Co.,Ltd, we are leading antenna manufacturer in China.
Ameison Antennas have been working in worldwide for over 6 tears. Our antennas cover GSM, CDMA, 3G, 4G, LTE, Wifi, Wimax, Wlan, UHF TV, VHF TV, RFID, Cluster, Marine and so on. Now we have a lots of MIMO and DAS models are hot selling.
After-sale service:
1)All of our product will have been strictly test before packing
2)All of our product will be well packed before shipping
3)All of our prodect will have one year quality warranty, free maintenance with warranty period!
OEM/ODM ORDERS ARE WELCOMED BY US.
