AMEISON 2 x 15 DBi 2500 - 2700 MHz Wall Mount Directional MIMO Patch Panel 2.6 GHz LTE Wimax Cpe Antenna

AMXW-2527VH-D15L60

Electrical Specifications

Frequency range(MHz)

2500~2700

Polarization

Vertical and Horizontal

Gain(dBi)

2×15

Half-power beam width(°)

H:65   V:14

Front-to-back ratio(dB)

≥25

Input Impedance(Ω)

50

V.S.W.R.

≤1.5

Isolation between ports

≥28dB

Cross-polar ratio

≥15dB@0º  ≥10dB@+/-60º

Sidelobe suppression for first sidelobe above horizon

15 dB

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical Specifications

Input connector type

2-N Female

Dimensions-mm (Height/Width/Depth)

405*140*28

Packing size(mm)

 440*160*90

Antenna weight (kg)

0.52

Radome material

ABS

Radome color

White

Mechanical tilt(°)

0~10

Operating temperature(°c)

-40~60

Rated Wind Velocity(m/s)

60

Waterproof Standard

IP54/ IP65/ IP67

Mounting way

wall-hanging or pole-holding

Mounting hardware(mm)

30 ~ 50
