Specifications
High gain;Aluminum alloy framework;Full day working;Optimized dimension;Vertical or Horizontal Mounting way;Factory Price.Antenna Manufacturer 1850-1990Mhz 15dBi 1.9GHz PCS LTE system heavy-duty anodized aluminum high gain directional yagi antenna
1850-1990Mhz directional yagi antenna
Gain is 15dBi
Antenna has 13 elements
Material is aluminum alloy framework
AMXY-1900-15
Feature:
High gain
Aluminum alloy framework
Full day working
Optimized dimension
Mounting way can be Vertical or Horizontal
Application:
Wireless bridging,client terminal antenna
1.9 GHz band applications
Personal Communication Service (PCS)
Multipoint applications
Cellular
LTE
|
AMXY-1900-15 Electrical Specifications | |
Frequency range(MHz) |
1850-1990 |
Bandwidth(MHz) |
140 |
Gain(dBi) |
15 |
Element |
13 |
Half-power beam width(°) |
H:40 V:37 |
Front-to-back ratio(dB) |
≥16 |
VSWR |
≤2.0 |
Input Impedance(Ω) |
50 |
Polarization |
Horizontal or Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N female or others |
Mechanical Specifications | |
Dimensions(mm) |
540*110*44 |
Cable length(m) |
0.3 |
Antenna weight(kg) |
0.32 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Clamp |
U-shape |
Mounting hardware(mm) |
Φ35~Φ50 |
This Yagi antenna features high gain and a 40° beam-width. It is ideally suited for directional and multipoint 1.9 GHz band applications such as Personal Communication Services (PCS) and 1.9GHz cellular band applications.
The antenna is supplied with a tilt and swivel mast mount kit. This mount provides 0-20 degree up or down tilt in 10 degree increments.
This High-Performance Yagi Antenna in an economical package combines accurate gain with a wide beam-width, ideally suited for directional applications in the 1900MHz PCS and LTE bands. This series of Yagi antennas provides the user with anodized aluminum boom, solid elements, low loss series 400 COAX, and rugged mounting hardware.
These features from Ameison are offered at cost-effective price points for the user who expects exceptional performance and value.
Order on line today!
