Specifications
These high gain parabolic antennas are perfect for point to point or point to multipoint WLAN applications.This is an affordable 2.4 GHz grid antenna priced much lower than comparable products from competing brands.
With 24 dBi gain, this antenna is a high gain antenna perfect for use on RVs, boats, or to cover long distances over land. Because of its higher gain, It can be used with longer extension cables compared to lower gain antennas.
With an N-female connector, it is easy to connect this antenna to any of its long range Wi-Fi adapters.
Contact our sales team for information about extension cables and pigtails, as Ameison's Wi-Fi adapters have RP-SMA connectors, so you will need an extension cable with the right type of connectors if you do not already own one.
An outdoor antenna is a great option for RVers and boaters because it allows you to receive outside of your RV or cabin walls. The height of this antenna also allows for high placement, which allows for you to maximize overall range.
More about this item:
Designed for multi-point wireless applications requiring wide coverage
Lightweight Fiberglass construction makes installation easy
Integral N-Female connector provides fast and easy cable connection
Designed for the 2.4GHz ISM band, supporting 2.4 to 2.483 GHz and provides superb performance in IEEE 802.11b/g WiFi and Bluetooth applications
Superior Performance and Weatherproof
2.4GHZ wifi Parabolic Antenna
High Gain
Low VSWR
Long distance transmmion
Wireless Bridges
2.4GHz Parabolic Antenna
AMXGR-2400-24
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Applications:
2.4 GHz ISM Band
IEEE 802.11b/g/n Wireless LAN Applications
WiFi Systems & Long-range Directional Applications
Point to Point Systems & Point to Multi-point Systems
Wireless Bridges, Backhaul Applications & Wireless Video Systems
|
AMXGR-2400-24 Electrical Specifications | |
Frequency range(MHz) |
2400~2483 |
Polarization |
Vertical or horizontal |
Gain(dBi) |
24 |
half-power beam width(°) |
H:10 V:14 |
Front-to-back ratio(dB) |
≥30 |
Input Impedance(Ω) |
50 |
VSWR |
≤1.5 |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Mechanical Specifications | |
Input connector type |
N Female |
Dimensions-mm |
600*900 |
Antenna weight (kg) |
3.6 |
Operating temperature:(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Mounting hardware(mm) |
35~75 |
