Specifications
5.1-5.8 GHz WiFi AntennaFactory price
All weather operation
Included Mounting bracket
Heavy-duty UV-Resistant Radome
Ameison 5.1-5.8 GHz Dual Polarized 15 dBi WiFi Antenna
Model No.: AMXP-5158VH-D15L60
Superior Performance
The AMXP-5158VH-D15L60 Flat Panel Antenna combines vertical and horizontal polarization with high gain over
multiple frequencies in a single enclosure. It is a professional quality antenna designed primarily for MIMO point-to-
multipoint and point-to-point applications in the 5.1 GHz and 5.8 GHz frequency bands.
This antenna incorporates advanced dual polarization technology that allows for the interoperability of two radios to
transmit and receive paths. This technology allows for the attenuation of unwanted signals from adjacent channels
and/or co-located equipment.
Rugged and Weatherproof
This aesthetically pleasing antenna features a heavy-duty UV-resistant plastic radome ideal for all-weather indoor
and outdoor operation. The AMXP-5158VH-D15L60 antenna is supplied with a tilt and swivel mast mount kit.
This allows quick installation at various degrees of up/down tilt for easy alignment.
Frequency Range: 5150-5850 MHz
Gain: 2*15 dBi
VSWR: < 1.5: 1
Polarization: Vertical & Horizontal
Vertical Plane Half Power Beamwidth: 14°
Horizontal Plane Half Power Beamwidth: 60°
Front to Back Ratio:>25 dB
Impedance: 50 Ω
Maxium Input Power: 200 W
Connector: Integral 2-N Female Connector
Dimension(L/W/D): 220*122*25 mm
Racome material: ABS
Lightning Protection: DC Ground
Weight (Approx.) including mounting bracket: 0.4 KG
Mounting Bracket: U Type clamp with bracket suitable for 30-50 MM diameter pole
Features:
- MIMO - Multiple-Input and Multiple-Output
- Dual Polarity feed system in single enclosure
- Two integral N-Type Female Connector
- UV-resistant radome for all-weather operation
- 5.1-5.8 GHz Wireless LAN systems
- Supports 1x2, 2x2, MIMO AP/Router
- Supports IEEE 802.11 a/n applications
- WiMAX, WISP, WiFi, Mobile Communication
- Homeland Security and Public Safety band
Packaging:
1.Bubble pp bag or EPE/inner box/carton(safe export packaging);
2.Different packaging patterns as per the customer's requirements.
Shipping:
If the order total amount for every shipment is less than USD 10,000, seller only do Ex-Works
Price; If more than USD 10,000, seller will undertake relevant FOB SHENZHEN price.
Shenzhen Ameison Communication Equipment Co., Ltd. are specialists in antennas.
We provide our customers with the antennas they need, when they need it.
We design, develop, research future technologies, test, prototype, manufacture and deliver.
Shenzhen Ameison Communication Equipment Co., Ltd. was established in 2009.which is one of the leading
professional antenna manufacturer in China and an integratednew-rising high-tech company in developing, designing
and manufacturing antennas andrelative products! Ameison has successfully entered China Unicom publicphone
system,China mobile wireless business phone system, China telecom3G system and our marketing occupancy has
grown step by step.
Our antenna products cover the complete range of frequencies from 88MHz to 5.8GHz Covering VHF, PMR,
UHF, TETRA, GSM-Cellular-3G, GPS, Wireless-LAN/WIFI and WIMAX, with a wide selection of accessories
encompassingcables, connectors and associated antenna products.
The purpose of the company sales: Quality first, Price reasonable.
We sincerely welcome the customers all over the world to visit our factories and cooperate with us!
OEM/ODM ORDERS ARE WELCOMED BY US.
What is MIMO (Mutiple Input, Mutiple output) antenna ?
MIMO (multiple input, multiple output) is an antenna technology for wireless communications in which
multiple antennas are used at both the source (transmitter) and the destination (receiver). The antennas
at each end of the communications circuit are combined to minimize errors and optimize data speed.
MIMO is one of several forms of smart antenna technology, the others being MISO(multiple input, single
output) an SIMO(single input, multiple output).
In conventional wireless communications, a single antenna is used at the source, and another single
antenna is used at the destination. In some cases, this gives rise to problems with multipath effects.
Whenan electromagnetic field (EM field) is met with obstructions such as hills, canyons, buildings, and
utility wires,the wavefronts are scattered, and thus they take many paths to reach the destination. The
late arrival of scattered portions of the signal causes problems such as fading, cut-out (cliff effect), and
intermittent reception (picket fencing). In digital communications systems such as wreless Internet, it
cancause a reduction in data speed and an increase in the number of errors. The use of two or more
antennas,along with the transmission of multiple signals (one for each antenna) at the sourceand the
destination, eliminates the trouble caused by multipath wave propagation, and can even take advantage
of this effect.
MIMO technology has aroused interest because of its possible applications in digital television (DTV),
wireless local area networks (WLANs), metropolitan area networks (MANs), and mobile communications.
