Sand Washing Machine/Gold washing machine
Sand washing machine of Our company adopts the advanced technology, in combination with the practical situation of domestic sand industry development of high efficiency sand washing equipment, highly clean, reasonable structure, large output, in the process of sand washing sand loss less, especially the transmission parts with water, sand isolation, so the failure rate is less lower than the commonly used sand washing machine, it is the best choice for the Sand washer industry upgrading in China.
Feed material is normally delivered between two to four feet from the feed end of the box and is subjected to an aggressive washing action resulting from the intermeshing paddle design. The paddles perform two functions: they help convey material and are the catalyst to material on material scrubbing. The clean material works uphill, between the shafts, and is discharged out the bottom of the box. Deleterious materials are absorbed into water and carried over a weir on either side of the box. The length of the washer box is dependent upon the percentage and tenacity of clay or the waste to remove.
Model |
Impeller Diameter(mm) |
Feeding Size (mm) |
Capacity(t/h) |
Power (kw) |
Overall Dimension(mm) |
XSD2610 |
Φ2600 |
≤10 |
30-60 |
7.5 |
3320*2125*2670 |
XSD2915 |
Φ2900 |
≤10 |
50-90 |
15 |
3810*2686*3085 |
XSD3016 |
Φ3000 |
≤10 |
80-160 |
18.5 |
4500*3206*3480 |
1, simple structure, stable running.
2, suitable for all kinds of working environment.
3, service life is longer, almost no wearing parts.
4, rarely need maintenance, so can greatly reduce the cost
5, bearing is separated from water and materials, avoid premature damage caused by pollution of rust machine phenomenon.
6, less material loss, choose high efficiency washing, washing can completely meet the requirements of high grade materials
Why customers choose our Bucket Wheel Sand Washer?
v In fact we are not in selling products,and more to help the customers to make a reasonable choice
v We have good after-sale service(erection and commissioning,operator training,spare parts supply)
v We have pre-defined query future,our products will be cheaper,
v energy-saving,simple structure,etc.
v As a professional exporter,our target is to serve worldwide clients with high-quality products,great reliability,devoted responsibility,professional service and honorable credibility to meet customers’requirements in all aspects.
