Specifications
PXJ Series High-Efficience Fine Impact Crusher1. Feeding size:120mm-200mm
2. More than 90% of products below 5mm
PXJ Series High-Efficience Fine Impact Crusher--From Baichy Equipment Manufactural
PCX fine crusher incorporates the advantages of the third stage sand making machine, hammer crusher, impact crusher, VSI crusher. It adopts stone-stone principle with a huge arc-shaped crushing cavity, which is a screen cavity with grate seam. We achieves the low cost operation of fine crusher completely for the specialized plate hammer.
Applications;
A mechanism for artificial sand, highway, railway, water conservancy, airport, construction, cement, refractory, metallurgical and other industries to produce high quality stone.
Processed Materials:
Widely adapted to granite, basalt, cement guessed, quartz, silicon carbide, ore, iron ore, bauxite especially crushing river gravel and other raw materials, to overcome the traditional sand making equipment only applies to soft rock (150MPa) materials shortcoming.
Working Principle:
Material into the cavity, falling on the high-speed rotary blow hammer, through the action between hammer and counterattack plate, the material in hammering preliminary crushing area. After the material has been repeatedly altofrequency hammering and counterattack drop on the diaphragm plates to from pile, slipped on a high-speed rotating dump tray, and then thrown into the counterattack panel of a high speed, then be board hammer mandatory to fight back, crushing, grinding.Thus, the material was crushed and grinding in a fall several times to achieve a fine crushing effect.
Parameters:
| Model | Feeder Opening Size(mm) | Feeding Size(mm) | Output Size(mm) | Capacity of Cement(t/h) | Capacity of Limestone(t/h) | Motor Power(kw) |
|---|---|---|---|---|---|---|
| PCX-8040 | 400×185 | 120 | 3(85%) | 20-30 | 35-45 | 45 |
| PCX-8060 | 500×250 | 180 | 3(85%) | 35-40 | 45-55 | 55 |
| PCX-8080 | 550×330 | 180 | 3(85%) | 35-45 | 55-65 | 55 |
| PCX-1010 | 1000×350 | 180 | 3(85%) | 45-55 | 65-75 | 75 |
| PCX-1210 | 1200×400 | 180 | 3(85%) | 80-100 | 50-100 | 110 |
| PCX-1212 | 1200×450 | 180 | 5(85%) | 100-110 | 90-100 | 132 |
| PCX-1414 | 1500×500 | 190 | 5(85%) | 100-150 | 100-150 | 160 |
| PCX-1616 | 1600×550 | 190 | 5(85%) | 170-210 | 190-250 | 250 |
| PCX-1818 | 1800×800 | 190 | 5(85%) | 250-270 | 280-310 | 315 |
High-Efficiency Fine Crusher features:
1,The device stable and reliable performance, process simplification, simple structure, reasonable and compact, easy to replace parts, repairs.
2,Changed three-level broken for second level broken, large production capacity, hammerhead long service life, environmentally friendly energy.
3,The unique structure of high chrome hammer, unique hard rock crushing Counterattack liner, unique inertial impact balancing device, a unique easy disassembly maintenance window. Exhaust particle size can be adjusted to simplify the crushing sand making process.
4,High-efficiency fine crusher than the same scale of traditional sand making machine yield high 30%~50% ( 5mm once yield accounted for more than 85%).
5,High-efficiency fine crusher saving 50% to 70% compared to the same scale of traditional sand making machine (one motor can produce).
6,High-efficiency fine crusher finished material is sand, stone cubic shape, strong Pressure-resistant ability, for high standard building needs (needle-shaped, less flaky-shaped).
7,High-efficiency fine crusher maintenance reduced by 50% to 60% than the same scale of traditional sand making machine (wearing parts can be purchased locally).
8,High efficiency fine crusher and matching the jaw crusher directly constitute the system of sand production line, eliminating the impact crusher and sand making machine, reduce the investment cost.
