Specifications
1.Hot sale Impact Rotary Rock Crusher2.Large crushing ratio
3.Even granularity
4.Simple structure&easy maintenance
5.ISO
CE Approved Impact Rotary Rock Crusher China Baichy Brand
1.Impact Crusher Usage and Application:
This Impact Crusher Plant mainly consists of Vibrating Feeder, Jaw Crusher, Cone Crusher or Impact Crusher, Vibrating Screen, Belt Conveyor and Control System, etc. It is completely capable to crush and screen limestone, marble, granite, basalt, river gravel and other hard stone materials, and produce sand & gravels with various granularities for construction and building industry. We are able to design and manufacture complete crusher plants with capacity from 30tph to 500tph, and to provide optimum and most economical solutions according to customers' requirements on stone specifications, output, application, etc.
2.Impact Crusher Working Principle:
Large stone materials from the storage hopper are evenly and continuously fed into jaw crusher through vibrating feeder for primary crushing; the crushed materials are transported to cone crusher or impact crusher for fine crushing through belt conveyor; then the materials are transported to vibrating screen to be separated into different sizes. The end products with desired sizes will be transported to the final product pile and those with big sizes will return to the cone crusher or impact crusher for re-crushing. This forms closed and continuously automatic cycles. The plant can be equipped with dust removing facilities to protect environment according to customers' requests.
1.High efficiency and energy saving.
2.Unique structure, no key connection
3.The blow bar with high chrome, unique impact liner
4.The end products are cubic, without tension crack, good shape, the size of discharging granularity is adjustable and simply crushing circuit.
5.Easy maintenance, simple and reliable operation.
3.Impact crusher Technical Data:
| Model | Spec of Rotor (mm) |
Feed Opening Size (mm×mm) |
Max Feed Size (mm) |
Processing Capacity (t/h) |
Motor Power (kw) |
Weight (Excluding Motor) (t) |
Overall Dimensions LXWXH( mm) |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 37-45 | 30-55 | 9.5 | 2400×1588×2660 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-80 | 55-75 | 12.2 | 2400×2250×2620 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-120 | 110-132 | 14.1 | 2690×2338×2890 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 130-180 | 132-160 | 18.6 | 2690×2688×2890 |
| PF-1010V | Φ1000×1050 | 400×1080 | 300 | 50-80 | 55-75 | 13 | 2400×2250×2620 |
| PF-1210V | Φ1250×1050 | 400×1080 | 350 | 70-120 | 110-132 | 14.9 | 2690×2338×2890 |
| PF-1214V | Φ1250×1400 | 400×1430 | 350 | 130-180 | 132-160 | 19.2 | 2690×2688×2890 |
| PF-1310V | Φ1300×1050 | 490×1170 | 350 | 70-120 | 110-160 | 13.5 | 2780×2478×2855 |
| PF-1315V | Φ1320×1500 | 860×1520 | 350 | 150-220 | 180-220 | 20.5 | 3096×3273×2667 |
| PF-1515V | Φ1500×1500 | 850×1580 | 350 | 220-280 | 280 | 29.5 | 3550×2835×3280 |
The company offers:le crusher.jaw crusher.stone ne crusher.impact crusher.portable crusher.primary crusher.crusher machine.mining machine.sand maker.sand washing machine.vibrating machine.feeder.vibrating nveyor.
If you want to know more information ,please check our website:
