Specifications
1.Famous Cone Crusher Spare Parts2.Large crushing ratio
3.Even granularity
4.Simple structure&easy maintenance
5.ISO9001
ISO Proved Cone Crusher Spare Parts From Crusher Manufacturer
1.Cone Crusher Features:
The foreign body is not broken by the crushing chamber overload the machine or for some reason, the spring release system of cone crusher to achieve insurance, cone crusher row ore increased. Foreign matter from the exhaust cone crusher chamber, such as foreign body stuck in the row of mine I use clear cavity, so that row mine continues to increase, so that is expelled Cone Crusher crushing chamber. Cone crusher in the spring under, behind mine mouth automatically reset, cone crusher machine back to work. Cone Crusher Series Crusher pm thick broken cone crusher, cone crusher and the crushed crushing three types of cone crusher can choose according to the different needs of users.
2.Structural features of cone crusher:
1. The machine structure is compact, high efficiency, with high accuracy bowl bearing reserves, and a centralized lubrication system, when the need to adjust the size of nesting I can start the hydraulic power cylinder through the promotion of adjustment, can not broken material into the crushing chamber
2. The machine grease seal, to avoid improper operation caused by the phenomenon of mixed water and oil, when the seals wear, due to the role of spring, can be automatically compensated, still make seals attached together, continue to play a sealing function, when seal wear is about 1/4-1/3 of the original thickness of the seal must be transposed.
3.Cone Crusher Main Technical Parameters:
Type |
Broken head base diameter (mm) |
Max feed size(mm) |
Output size range(mm) |
Broken capacity(t/h) |
Motor power(KW) |
Eccentric shaft speed(r/min) |
Weight(t) |
Overall dimension(mm) |
PYB600 |
600 |
75 |
12-25 |
40 |
30 |
356 |
5 |
2234×1370×1675 |
PYD600 |
600 |
40 |
2-13 |
12-23 |
30 |
356 |
5.5 |
2234×1370×1675 |
PYB900 |
900 |
115 |
15-50 |
50-90 |
55 |
333 |
11.2 |
2692×1640×2350 |
PYZ900 |
900 |
60 |
5-20 |
20-65 |
55 |
333 |
11.2 |
2692×1640×2350 |
PYD900 |
900 |
50 |
3-13 |
15-50 |
55 |
333 |
11.3 |
2692×1640×2350 |
PYB1200 |
1200 |
145 |
20-50 |
110-168 |
110 |
300 |
24.7 |
2790×1878×2844 |
PYZ1200 |
1200 |
100 |
8-25 |
42-135 |
110 |
300 |
25 |
2790×1878×2844 |
PYD1200 |
1200 |
50 |
3-15 |
18-105 |
110 |
300 |
25.3 |
2790×1878×2844 |
PYB1750 |
1750 |
215 |
25-50 |
280-480 |
160 |
245 |
25.3 |
3910×2894×3809 |
PYZ1750 |
1750 |
185 |
10-30 |
115-320 |
160 |
245 |
25.3 |
3910×2894×3809 |
PYD1750 |
1750 |
85 |
5-13 |
575-230 |
160 |
245 |
50.2 |
3910×2894×3809 |
PYB2200 |
2200 |
300 |
30-60 |
590-1000 |
280 |
220 |
80 |
4622×3302×4470 |
PYZ2200 |
2200 |
230 |
10-30 |
200-580 |
280 |
220 |
80 |
4622×3302×4470 |
PYD2200 |
2200 |
100 |
5-15 |
120-340 |
280 |
220 |
81.4 |
4622×3302×44 |
