Double Roller Crusher--From Baichy Equipment Manufactural
Roll Crusher (or Roller Crusher) is used for middle crushing and fine crushing of all kinds of ores and rocks under mid-hardness in mine, chemical industry, cement, building materials and other industrial sections. This crusher has simple structure and can be operated conveniently. Ideal product size depends on adjusting space between two rollers.
Applications:
Applicable in the cement, chemical, electric power, mining, metallurgy, building materials, refractories, coal and other bulk materials industries brittle beginner, intermediate crushing.
Processed Material:
Compressive strength less than 350MPa of various coarse, medium and fine materials, such as: river gravel, granite, basalt, iron ore, shale, limestone, coal, quartz, diabase, marble, copper ore.
Working Principle:
Roll Crusher is made up of two cylindrical rolls which are installed horizontally. The two rolls rotate in different directions, materials fall on top of the rollers and enter crushing chamber under the action of roll surface friction to be crushed by the rollers, and the final product is discharged from outlet. The crushing process is continuous. The crusher has strong discharging force, so even wet materials can also be discharged.
Parameter:
| Model | Feeding Size (mm) | Output Size (mm) | Capacity (t/h) | Motor Power (kw) | Weight(kg) |
|---|---|---|---|---|---|
| 2PG-400X250 | ≤25 | 1--8 | 5-10 | 11 | 1500 |
| 2PG-400X500 | ≤30 | 1--15 | 10-20 | 22 | 2600 |
| 2PG-610X400 | ≤40 | 1--20 | 13-35 | 30 | 4500 |
| 2PG-750X500 | ≤40 | 2--20 | 15-40 | 37 | 12250 |
| 2PG-900X500 | ≤40 | 3--40 | 20-50 | 44 | 14000 |
Double Roller Crusher features:
This series of Double Roller Crusher mainly consists of roller, roller support bearings, compaction and adjusting device and driving means and others. With small, large crushing ratio, low noise, simple structure, easy maintenance advantages, high productivity, material to be broken uniform size, easy maintenance, overload protection sensitive. Applicable dry ore, wet ore, clay mineral and sticky ore, do not plug but safe and reliable.
Double roller crusher with double overload and over iron protection:
1,The use of hydraulic couplings, when iron overload too, crusher stops. 2,Crusher tooth axis can inversion and discharge the mineral material can not be broken or iron.
