Help CenterFtth Channel 27 1.25G 1555.75nm Transceiver 120km Dwdm Sfp
Related Products
-
Channel 511.25G 1536.61nm Dwdm Sfp Optical Transceiver 120kmUS$ 1 - 492MOQ: 1 Piece -
10G SFP+ BIDI Optical Transceiver 10KM T1270/R1330nmUS$ 1 - 254.5MOQ: 1 Piece
-
Hot-pluggable 1.25G 1310nm FP SM 20km LC Optic Transceiver SFP-1.25G-LXUS$ 9 - 11MOQ: 100 Pieces
-
Factory Supplier 1550nm SFP 10g 80km Fiber Optical TranceiverUS$ 356 - 356MOQ: 1 Piece
-
10g 1550nm 80km SFP Duplex Fiber Optic SFP Transceiver Sfp-10g-zrUS$ 356 - 356MOQ: 1 Piece
DWDM SFP Transceiver 120kmSpecifications
1. 1.25g DWDM SFP module
2.1555.75nm wavelength
3. 120km distance
4. DWDM SFP 120km
Features
1.Hot-pluggable SFP Footprint
2.Dual LC Connector
3.Wide Distance Supported from 500m to 120km
4.Digital Diagnostic Functions Optional
5.Metal Enclosure for Lower EMI
6.Operation Temperature Range 0~70oC or -40~85oC Optional
7.Single +3.3V Power Supply
8.RoHS-6 Compliant
Description
Rollball DWDM SFP Transceiver exhibits excellent wavelength stability, supporting operation at 100 GHz channel, cost effective module. It is designed for DWDM SONET/ SDH, Gigabit Ethernet and Fiber- Channel applications.
The transceiver consists of two sections: The transmitter section incorporates a colded DFB laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Rollball DWDM SFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage, laser temperature and TEC current.
Ordering information
Part Number |
Product Description |
RDSFP-XX24-08CD |
DWDM, 1.25Gbps, 80km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring |
RDSFP-XX24-12CD |
DWDM, 1.25Gbps, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring |
RDSFP-XX48-08CD |
DWDM, 2.5Gbps, 80km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring |
RDSFP-XX48-12CD |
DWDM, 2.5Gbps, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring |
RDSFP-XXMR-12CD |
DWDM, Multi-rate, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring |
