Help CenterYS-PC Series Gravure Printing Machine
Related Products
-
YS-GH Computerized Gavure Coating MachineUS$ 30,000 - 200,000MOQ: 1 Set -
YS-ZD Rotogravure Printing MachineUS$ 30,000 - 200,000MOQ: 1 Set
-
YS-ZN Rotogravure Printing MachineNegotiableMOQ: 1
-
YAD-C 1050 Computerized Printing Machine/adhesive Tape Automatic MachineUS$ 30,000 - 200,000MOQ: 1 Set
-
YS-Z Computerized Middle Grade Printing MachineUS$ 30,000 - 200,000MOQ: 1 Set
Specifications
Machines in this series are applicable for continuous multi-color printing on rolling materials in good printing performance.USAGE:
Machines in this series are applicable for continuous multi-color printing on rolling materials in good printing performance such as cellophane, BOPP, PET, PVC, PE, nylon , aluminum foil, and paper, broadly applied for all types of super quality printed matters
MAIN PARAMETERS:
Type |
YS-PC |
Printing width |
1600mm |
Printing color group |
1-6 color |
Specification of roll |
φ100-φ300mm |
Printing speed |
10-60m/min |
Machine speed |
80m/min |
Accuracy of registration |
Longitudinal:±0.20mm; Landscape orientation: ±0.20mm |
Color distance |
1400mm |
Total power |
60kw |
Machine weight |
11ton |
Overall size |
1300×2900×2500mm |
FUNCTION AND CHARACTERISTICS
1.The whole set is in permutation and combination style,multicolor a single continuous two-sided printing.
2. Main drive system, and regulating speed motor speed control speed.
3. Recoiler double-torque motor, and discharge using magnetic brake.
4. Drying System dual-drying Road, enclosed from top to bottom using axial flow fan hot temperature and the cooling of each wind energy, fast-drying, automatic temperature control system with meters function.
5.Printing ink circulating system, inflatable type shaft draw in and draw out
6.Drives using high-precision gear box.
7.Separated Rewinding & unwinding double work station, non-stop carrying material.
REQUIREMENT:
1.Printing color and back-printing can be adjusted according to specification.
2.Axis or w/o Axis equipment can be chosen according to specification.
