Home > Electrical & Electronics > Transmitter > Pressure Transmitter > Professional Mould Design Factory Directly Rs485 Digital Tire Pressure Transmitter of SUPCON

Professional Mould Design Factory Directly Rs485 Digital Tire Pressure Transmitter of SUPCON

Name: Professional Mould Design Factory Directly Rs485 Digital Tire Pressure Transmitter of SUPCON
Brand: SUPCON
SKU: 126057131
Availability: InStock

Professional Mould Design Factory Directly Rs485 Digital Tire Pressure Transmitter of SUPCON thumbnail-1

Professional Mould Design Factory Directly Rs485 Digital Tire Pressure Transmitter of SUPCON photo-1

US$ 400 - 600 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

SUPCON

Model Number:

SKE Level Transmitter

Contact Supplier Request Quote Chat Now

Zhejiang Supcon Instrument Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai NingBo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name SUPCON

Model Number SKE Level Transmitter

NEW! Factory supply rs485 digital tire pressure transmitter

WHY CHOOSE US?

1.Factory

2.Leading professional manufacturer of rs485 digital tire pressure transmitter.

3.Our factory owns a group of high quality and high-tech professional designers and staff members.

Our major products are as below:
Transmitter,CJT Transmitter,CXT Transmitter

CLICK HERE,BACK TO HOMEPAGE,YOU WILL GET MORE INFORMATION OF US!

Features
1	High accuracy 0.065% accuracy for all calibrated spans is the standard feature for pressure transmitter covering 1.3 to 10000kPa, 0.04% accuracy as option. The compositive monocrystalline piezoresistive sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment.
2	Minimum environmental influence The Advanced Cell design, which protects the pressure sensor against changes in temperature, static pressure, and overpressure substantially reduces total measurement error in actual field applications.
3	Application flexibility Various options that render the CXT suitable for almost any process applications include: – Full range of hazardous area approvals – Built-in RFI filter and lightning arrester – 5-digit LCD meter with engineering unit – Stainless steel electronics housing – Wide selection of anticorrosion materials

Specifications
1	Span, range Working pressure Span (kPa) Range (URL) Over range Type (MPa) Min. Max. KPa MPa SKG 00 -0.04~0.4 1.6 40 40 0.2 SKG 01 -0.1~0.25 2.5 250 250 0.75 SKG 02 -0.1~0.8 8 800 800 2.4 SKG 03 -0.1~3 30 3000 3000 9 SKG 04 -0.1~10 100 10000 10000 15 Note: LRL= Lower Range Limit; URL= Upper Range Limit. To minimize environmental influence, span should be greater than 1/40 of the max. span in most applications.
2	Process temperature, Lower range limit Fill Fluid 13th digit code Process temperature Lower range limit Silicone oil Y, G (-40~100)°C 2.7kPa abs Fluorinated oil W, A, D (-20~80)°C Atmospheric pressure
3	Performance Specifications for Linear Output (Zero-based calibrated ranges, reference conditions, silicone oil fill, 316L SST isolating diaphragms and 4 to 20mA analog output in linear mode.) Accuracy rating (including linearity, hysteresis, and repeatability) For spans greater than 1/10 of URL: ±0.065% of span or ±0.04% of span (21st digit: H) Temperature effect Effect per 28°C change between the limits of -40°C and +85°C Over range effect Zero shift: ±0.2% of URL for any over range to maximum limit Stability ±0.1% of upper range limit (URL) for 10 years. Mounting position effect Zero shift: less than 0.12kPa for a 10° tilt in any place (0.24kPa for 13th digit code "W","D","A").No effect on span. This error can be corrected by adjusting zero.
4	Physical Specifications Process-wetted parts material Material code (7th digit in "Ordering Code") Process cover Process-wetted body Diaphragm Wetted sensor body V CF8M 316L SST 316 SST W CF8M Hastelloy-C 316 SST J CF8M 316L SST + Au coating 316 SST H CF8M Hastelloy-C Hastelloy-C P CF8M 316L SST+ PTFE coating 316L SST T CF8M Tantalum 316 SST Non-wetted parts material Electronics housing Low copper die-cast aluminum alloy finished with polyester coating (silver), or CF8M, as specified. Electronics housing cover Low copper die-cast aluminum alloy finished with polyester coating (atrovirens), or CF8M, as specified. Environmental protection IEC IP67 Mass (weight) Transmitter approximately 3.1 to 3.6kg without options Electrical connections ½-14NPT or M20×1.5 conduit, as specified. External terminal M4 screw Process connections ¼-18NPT Mounting On 50A(2B) pipe using mounting bracket, direct wall mounting or direct process mounting. Transmission unit position The transmission unit can be turned at 90° or 180°in the clockwise or counterclockwise direction.

Item Name	3151 replacement smart hart protocol differential pressure transmitter with oled display
Material	Metal
Color	silver and atrovirens
Process	Casting,Stamping,Polishing,Filling Silicon Oil, Painting, Assembly, Calibrating, Packaging
Custom Desigh	Welcome
Service	OEM&ODM
MOQ	1pcs
Sample	Available
Sample Cost,The cost will be returned after placing an order	USD600
Sample Lead Time	7-15 Days
Payment Terms	T/T, LC at sight,west union,paypal
Packing	carton package with protection material
Production Time	15-30 Days
Delivery Port	Ningbo or Shanghai

Q: Are you a manufacture or a trading company?

A: We are a 20-year-manufacturer engaged in the field of cleaning products, and we have got the permit of import and export as well.

Q: Where is your factory located? How can I visit there?

A: Our factory is located in Hangzhou, China. 25 Minutes by car far away from Xiaoshan Airport.

Q: How can I get the rs485 digital tire pressure transmitter samples? What's the lead time?

A: Samples could be sent within one week, the lead time is 35-45 days..

Q: Do you provide rs485 digital tire pressure transmitter ODM/OEM service?

A: OEM/ODM is welcome, there are 25 persons in our R&D team, and customized colours is optional. From the concept to finished goods, we do all (design, prototype reviewing, tooling and production) in the factory.
