aluminum profile CNC machining center 4 axis CNC aluminum milling drilling machine center

Product Description

Feature:
For curtain walls, aluminium profiles and so on.
Drilling and milling functions.
Spindle: Italy HSD, 18000 rpm/min.
Industrial personal computer: Taiwan ADVANTECH.
Servo motor and driver: Japan OMRON.
Ball screw and square guide rail: Japan ABBA.
A axis rotate the work piece between -90°and +90°according to request, so it is available to columnar work piece.
Half dry cooling system, with plant oil, no damage to workers and environment.
Continue to work from the breakpoint.
Equipped with professional software CAD-CAM.
Light curtain to protect workers effectively.
Lock Knife block is convenient to change cutters.

Parameter:
Power 380V/50Hz/11kw
Air pressure 0.5-0.8Mpa
X axis stroke 3600mm
X axis speed 120m/min
Y axis stroke 380mm
Y axis speed 80m/min
Z axis stroke 400mm
Z axis speed 60m/min
Max. processing speed 3m/min
Location error ±0.05mm
Resetting error ±0.02mm
Processing error ±0.1mm
Surface roughness Ra12.5μm
Overall dimension 5380x1890x2240mm
Weight 3000kg

max. tool diameter 13mm

Processing Samples :
