pvc window machine 4 head welding machine,pvc windows machinery

Product Application:

 WPL130 welding and cleaning line for door and window is typically used for welding and cleaning PVC door and window frame.

 It welds four corners of PVC profiles and cleans the welded corners.

This welding-cleaning production line is mainly composed of welding unit, transfer unit, manipulator and corner cleaning unit.

Thanks to Parker's unique, rigid and aesthetic design, this welding and cleaning line has high working speed. The original robot system can convey the corners to the cleaning unit without time loss. Besides, our welding-cleaning production lines have passed CE and UL certifications.

Features

1. Whole Machine

WPL130 welding and cleaning line adopts imported computer control system with high reliability and production ability. It can automatically program and select processing programs.

2. Welding Unit

This welding-cleaning production line uses horizontal structure for stable running. It realizes automatic size error compensation, high processing precision and high stability. Special locating system and impaction device ensure its size precision. Steel stand and low center of gravity ensure stable welding of this welding and cleaning line.

3. Cleaning Unit

This welding-cleaning production line owns eight groups of different cutters to achieve the cleaning of welded corners. Adopting four-axis servo-drive system contributes to high processing efficiency. Imported computer system and drive system also ensure high reliability of this welding and cleaning line. It is not necessary to change cutters to process more than one hundred profiles. Error compensation between arc and straight line is possible and gives good cleaning appearance.

4. Transfer Unit and Manipulator

Transfer unit of this welding-cleaning production line is used for automatically conveying the finished frame or sash after welding. Manipulator is applied for transferring the frame or sash to the precise position.

Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Brazil Customer:

DMCC82 CNC Milling Drilling    Machine Center

Dubai Customer:

DMCC6:CNC Machine Center for aluminum profile

USA Customer:

PVC Window Machine line

Indian Customer:

Insulating glass production line

PVC/UPVC Window Machine Line :

PVC Window Cutting Saw Machine ;

PVC Window Welding Machine:

PVC Window Corner Cleaning machine:

PVC Window water slots ,lock holes making machine ;

Aluminum Window Door Making Machine Line :
Aluminum Window Cutting Saw Machine ;
Aluminum Window Welding Machine:
Aluminum Window Corner Cleaning machine:
Aluminum Window water slots ,lock holes making machine ;

Aluminum Window Corner Cutting Machine

Aluminum window end milling machine;

Aluminum window copy router machine,punching machine;

Insulating Glass Production line

3 Axis CNC milling drilling machine center for aluminum profile ,curtain wall

4 axis machine center

5 axis machine center
