unitized curtain wall line curtain wall fabrication machine
Model: IGV27-S
Video link for machine:
https://youtu.be/0ulVBIGZgDo ( video for insulating glass line: glass washing & pressing )
https://youtu.be/zE0jsZv0tX8 ( CNC glass cutting line )
https://youtu.be/Vm7zIu-KAZ0 ( butyl extruder machine )
https://youtu.be/oKe7RYSrvyg ( desiccant filling machine )
https://youtu.be/Z5NmPvIhCag ( aluminum spacer bending machine )
https://youtu.be/2k5SSu_FfVE ( rotary coating table )
Features:
1. unitized curtain wall line curtain wall fabrication machine This machine has self-diagnose system, easily check the error.
2. It can identify the Low-E glass and coating glass automatically. So it can stop the first hard brush automatically protecting the glass from scratching.
3. The PLC and proximity switch adopt OMRON imported for Japan.
4. It has high precision and works steadily. Because we adopt the screw and flat press.
5. Servo driver and servo motor imported from YASAKWA Japan can control glass-combining precisely.
6. This machine adopts inverter control transmission motor. So it can easily slow down and accelerate.
7. It can produce big and small scale, tri-glass and insulating glass(Optional)
Parameters:
Voltage: |
380V 50HZ |
Power: |
15KW |
Air consumption: |
200L/min |
Max. process dimension: |
2700mm x 5000mm |
| Min. process dimension: | 250mm x 450mm |
| Max. thickness: | 40mm |
| Convey speed: | 12-40m/min |
| Cleaning speed: | 0-8m/min |
| Max. processing speed: | 40m/min |
| Overall dimension: | 22800mm x 2800mm x 5000mm |
Other Glass Machines:
Factory:
Samples:
Exhibitions:
Factories of Customers:
Customers Visit:
Parker Service Team:
Packing & Loading:
Contact Information:
JINAN PARKER MACHINERY Co.,LTD
Website: ;
Contact: Linda
Cell: 0086-182-5416-1395
Skype: lindaredouble
Email: linda
