Specifications
SHB-E water circulating vacuum pump1.flow 300 L/min
2.max.vacuum degree 0.098Mpa
3.Cooling fluid pipe Material 1Cr18Ni9Ti
SHB-E water circulating vacuum pump
I. CHARACTERISTICS OF USES:
The vacuum pump is specifically developed for matching the medicine purification, large-volume unit, middle-scale test, small and middle scale production process, the bleed air flow of which is large. It is suitable for the industries such as chemical industry, pharmacy, biochemistry, foodstuff, pesticide, agricultural engineering, biological engineering.
•Can be used for several Rotary Evaporator (the quantity is determined by the specification of the rotary evaporator) of 10~50 liters working simultaneously.
•Can be used for simultaneous working of several Reaction Kettles (the quantity is determined by the specification of the reaction kettle) .
•Replace spiral slice vacuum pump. No problems of pump eroding or oil emulsifying of vacuum pump.
•Water tank, condenser tube and circulating pump adopt stainless steel material (ANSI standard) which can bleed corrosive gas.
•The external part can be cooled by connecting with refrigeration facilities or cooled by tap water. Make a constant water temperature of 4-10°C in the water flume to guarantee the best vacuum degree.
II. Technical data:
Model |
Power(W) |
Powersupply (V/Hz) |
Flow(L/min) |
Lift(m) |
Maximum VacuumDegree (MPa) |
Air sucking amount |
Air sucking Diameter |
Safety functions |
Cooling fluid pipe |
Dimension(mm) |
|
Volume(L) |
Materials |
||||||||||
SHB-E |
3000 |
380/50 |
300 |
30 |
0.098 |
300 |
25 |
Check valve |
180 |
1Cr18Ni9Ti |
950L×810W×970H |
