WLDH -15 Plastic Mixing Machine

Specifications

1.WLDH -15 Plastic Mixing Machine for high efficiency horizontal ribbon mixer.
2.Paddle Mixing Machine
3.Small CE paddle mixer

WLDH -15 Plastic Mixing Machine



Applications
The WLDH -15 Plastic Mixing Machine is generally used in the mixing of viscous or adhesive powder material, or the mixing of powder which needs to add liquid, and paste material. Meanwhile, because it is difficult to clean viscous material, the machine is suitable for the mixing case, where the output is large and there is no need of displacing material variety frequently.

Our WLDH -15 Plastic Mixing Machine comprises of U-shaped container, transmission parts and ribbon agitating blades which usually have double or triple layers with outside screw gathering the material from sides to center and inside screw transmitting the material from center to sides to form convection mix.

Ribbon mixer has a good result in the mix of viscosity or cohesion powder and of putting liquid and mash material into the powder. The cylinder cover can be fully open so as to clean and change the device.



Specifications:

The WLDH -15 Plastic Mixing Machine is a high efficiency horizontal ribbon mixer.



Principle:

The WLDH -15 Plastic Mixing Machine is composed of container, screw stirring paddles and transitional parts; the screw paddle are generally made into 1 layer or 3 layers, the outer screw converge is the material to the center from two sides, and the inner layer of screw conveys the material to the two sides from the center, so as to from convection mixing.



Features:
Big coefficient of loading, small occupied area.
It is difficult to clean when it is used to mix viscous or adhesive material.



Technical paramenters:

Model/Project	All Volume (m3)	Loads coefficient	power (kw)	Size	weight (kg)
WLDH -0.1	0.1	0.4-0.8	3	1190×740×770	330
WLDH -0.3	0.3		4	2030×630×980	720
WLDH -0.5	0.5		7.5	2320×730×1130	980
WLDH -1	1		11	2800×920×1320	1700
WLDH -1.5	1.5		11	3180×1020×1550	1800
WLDH -2	2		15	3310×1120×1640	2100
WLDH -3	3		18.5	3750×1290×1820	3000
WLDH -4	4		22	4220×1400×1990	3980
WLDH -5	5		22	4220×1500×1990	4620
WLDH -6	6		30	4700×1610×2260	6180
WLDH -8	8		37	4420×2150×2470	8200
WLDH -10	10		45	5520×2960×2720	8920
WLDH -12	12		45	5720×3010×2840	9520
WLDH -15	15		55	5840×3540×2940	9950













Service:
A. To pick up machine more easy & correct.
First, We need client to provide below information about their product:
1) The requirement of raw material: we require powder or grains with good fluidity & dry, can fall down from cone charging barrel.
2) We need know the size, shape of tablets / pills. Yield(capacity) in your request.
So we can figure out if our machine can compress and which models will meeting with your requirement.
B. We can design, customize and make dies for customers.
