EYH1500 Two Dimensions Powder Mixing Machine
Applications:
The EYH1500 Two Dimensions Powder Mixing Machine is widely used in pharmaceutical, food, dye, feed, chemical fertilizer and pesticide industries and especially suitable for mixing various solid materials with large volume (1,000tp 12,000litres).
Working Principle:
The mixing tank is a cylinder-shape barrel without any stirring device inside, which makes the self-rotation around its axis and also produces onvert swing movement around its plane axis synchronized. Therefore, the target materials inside the barrel could be mixed diffusely and moveably. It is featured with short mixing time, good uniformity, big output, convenient to discharging, etc.
Technical Parameters:
Model |
Barrel volume (L) |
Loading capacity (L) |
Max Loading Weight (Kg) |
Turn/Swa (r/min) |
Total Power (Kw) |
Overall Dimension (X*Y*Z*Z1) (mm) |
Y1 (mm) |
Barrel Dia. (mm) |
Total Weigh |
Barrel weight |
EYH300 |
300 |
180 |
90 |
18/11 |
1.3 |
925*905*1480*1360 |
1460 |
600 |
340 |
60 |
EYH600 |
600 |
360 |
180 |
16/9 |
2.2 |
1145*1105*1750*1600 |
1650 |
750 |
1150 |
140 |
EYH800 |
800 |
480 |
240 |
10/6 |
3 |
1305*1255*1900*1790 |
1990 |
820 |
1600 |
200 |
EYH1000 |
1000 |
600 |
300 |
8/6 |
3 |
1375*2255*1910*1770 |
2950 |
900 |
1700 |
240 |
EYH1500 |
1500 |
900 |
450 |
9/5 |
4.4 |
1505*2445*2200*2100 |
3200 |
1000 |
2000 |
320 |
EYH2000 |
2000 |
1200 |
600 |
8.5/5 |
5.2 |
1635*2445*2255*2120 |
3250 |
1130 |
2600 |
430 |
EYH3000 |
3000 |
1800 |
900 |
7/4.5 |
7.0 |
1905*2755*2600*2420 |
3650 |
1300 |
3500 |
620 |
EYH4000 |
4000 |
2400 |
1200 |
7.8/5 |
9.5 |
2035*3205*2755*2550 |
4200 |
1400 |
4100 |
700 |
EYH6000 |
6000 |
3600 |
1800 |
7/4 |
13 |
2265*3805*3230*2960 |
5040 |
1600 |
6100 |
1100 |
EYH8000 |
8000 |
4800 |
2400 |
6.7/4.5 |
13 |
2555*4305*3680*3390 |
5510 |
1800 |
7900 |
1450 |
EYH10000 |
10000 |
600 |
3000 |
6/4.2 |
18.5 |
2665*4355*3800*3420 |
5670 |
1900 |
10000 |
1700 |
EYH12000 |
12000 |
7200 |
3600 |
6/4 |
18.5 |
2765*4985*4120*3760 |
6500 |
2000 |
13000 |
2000 |
EYH15000 |
15000 |
9000 |
4500 |
6/4 |
22 |
3035*4855*4500*4150 |
6700 |
2300 |
15000 |
2500 |
EYH20000 |
20000 |
12000 |
6000 |
5/3.5 |
30 |
3295*5155*5000*4500 |
7050 |
2500 |
18000 |
3100 |
Our Company is one famous group and apply itself to R&D,manufacture machinery for Pharmaceutical, Chemical, food and so etc fields.
Our Main Products are: Tablet press,Mixer,Crusher,Granulator,Dryer,Coater,Packing machine,Filling Machine,Miller and Pulverizer, Feeder,Oven, Deduster, Dust Collector, vibration sieves...
We also supply punch die sets and spare parts in standard or not.
