Best quality new coming certificate paving block machine
Introduction of certificate paving block machine:
1.This machine is multifuctional. Various bricks such as road verge bricks,river channel bricks,slope-protecting bricks,plaza pavement bricks,dock
bricks,grass-planting bricks etc. can be produced only by exchanging its mould.
2.By low frequency material feeding,high frequency vibrating and pressing and vibrating both by table and mould, the concrete can be completely liquidized and air discharged within 2 or 3 seconds, in order to obtain high density and high strength.
3.As the advanced hydraulic ratio control technology is adopted so that the oil pressure of each branch of the circuit can be controled at will and various bricks with the same high quality can be produced using different raw materials.
4.PLC intelligent control system which equiped with data input and output device,advanced safety logic and fault self-diagnosis system is adopted in full of the production procedure.
Specification of certificate paving block machine:
1 |
Dimension of host machine |
4000x1800x2800 |
|
6 |
Host machine power |
29.85kw |
2 |
Weight of host machine |
5.5T |
7 |
Vibration force |
40-50KN |
|
3 |
Molding area |
1006x600 |
8 |
Mixer model |
JS500 |
|
4 |
Water consumption |
5-6Ton/day |
9 |
Pallet size |
1010x550x25mm |
|
5 |
workshop area |
250-300m2 |
10 |
Voltage |
380/415/440 |
Productivity:
No |
Size(LxWxH) |
Reference pic |
Pcs/Mould |
Pcs/Hour |
Pcs/Shift |
1 |
400x200x200mm |
|
4 |
720-840 |
5760-6720 |
2 |
400x100x200mm |
8 |
1440-1680 |
11520-13440 |
|
3 |
400x150x200mm |
6 |
1080-1260 |
8640-10080 |
|
4 |
400x250x200mm |
3 |
540-630 |
4320-5040 |
|
5 |
230x110x70mm |
|
24 |
4320-5040 |
34560-40320 |
6 |
200x100x60 |
|
16 |
2880 |
23040 |
7 |
200x163x60 |
|
8 |
1440 |
11520 |
Picture of certificate paving block machine:
Products Related:
Process Flow:
Raw Material:
Scale of raw material
1. 8%-10% cement ,30%-40% sand, 50%-60% stone(less than 15mm)
2. 8% cement,60% sand,Fly ash 30%,2% gypsum.
Delivery Terms:
1.Price is based on FOB QingDao ,China
2.Payment:by irrevocable letter of credit,payable at sight for full amount of invoice value ,or T/T, 30% down payment,70% upon machinery completion.
3.Delivery:30 days upon receipt of down payment or L/C at sight.
4.Shipping Marks:We will send engineers and one translator to install the equipment;The buyer shall bear all expenses (include:visa/flight ticket/hotel/food/traffic, and extra subsidy usd 50/day/person for the first week,usd 100/day/ person fo later time)
5.We test brick making for every machine before delivery
6.Voltage and Hertz Demand: Depended on customer.
Guarantee and warranty:
1.Free technical training of installation .
2.The machine lifetime warranty.(our maintenance team can go to your country at any time)
Certificates:
Contact Information:
Person:Linda
Skype:linda.jia5
Mobile:+86 18763375732
