Specifications
LTE FDD/TDD/DC-HSPA+/HSPA+/UMTSDD800/900/1800/2100/2600MHz
DL 300Mbps/UL 50Mbps
up to 64 devices
Huawei E5175s-22 LTE FDD 800/900/1800/2100/2600Mhz TDD2600Mhz Cat6 300Mbps router
HUAWEI E5175s-22 LTE Cat6 Router Technical Specifications | ||
Model Number |
HUAWEI E5175s-22 |
|
SIM Lock Status |
Unlocked, SIM Card Free |
|
Form type |
4G LTE Router /LTE Wireless Gateway |
|
Opterator Model |
Vodafone B4000 |
|
Chipset/platform |
Hisilicon |
|
Category |
LTE Category 6 (3GPP Release 11) WiFi Router |
|
Network Bands | ||
4G/LTE Frequency Bands |
Huawei E5175S-22 : Band 1/3/7/8/20/38 (FDD 800/900/1800/2100/2600MHz & TDD 2600MHz) |
|
3G UMTS/WCDMA Bands |
2100/900Mhz |
|
2G GPRS/GSM/EDGE |
850/900/1800/1900 MHz |
|
Data Rate Speed | ||
4G/LTE FDD link Speed |
Downstream: 300Mbit/s |
Upstream: 150Mbit/s |
4G/TD-LTE link Speed |
Downstream: 224Mbit/s |
Upstream: 20Mbit/s |
3G DC-HSPA+ Link Speed |
Downstream: 42Mbit/s |
Upstream: 5.76Mbit/s |
3G HSPA+ Link Speed |
Downstream: 21Mbit/s |
Upstream: 5.76Mbit/s |
3G UMTS Link Speed |
Downstream: 384Kbit/s |
Upstream: 186Kbit/s |
Other Features | ||
MIMO Support |
YES, 2 X 2 MIMO |
|
WiFi Support |
802.11 b/g/n/ac, WiFi peak speed to 300mbps, 2.4GHz/5GHz |
|
Maximum Users Supported |
64 Users |
|
SD Card Slot |
YES, SD card up to 32GB |
|
USB Type |
1 x USB 2.0 for host sharing and Printer |
|
External Antenna |
2 External antenna (SMA female) |
|
Ethernet Port |
4 x RJ-45 (One for WLAN/LAN, Three for LAN) |
|
Telephone port |
2 x RJ-11 for Analog Telephone |
|
Battery |
No |
Working time: |
Dimensions |
||
Weight |
450g |
|
OS Supported |
Windows/Linux/Mac OS |
|
IPV 6 Support |
Yes |
|
Supported Operators |
Telekom, Vodafone, Orange, E-plus, A1,3 UK, EE, STC, Telstra, |
|
