Specifications
slit and rewind plastic film: PE, PP, OPP, paper and non woven rollplastic film slitting machine
vertical type
high speed
Function:
This film / paper slitting rewinding machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. And can cut edge, separate and cut material according to different requirements during production.
Performance and Features:
1. This machine is a kind of vertical slitting & rewinding machine
2. Independent master control panel, more flexible and even easier operation.
3. Automatic EPC for unwinding, photocell is suitable for tracking the edge and color of transparent material.
4. Air inflatable shaft for unwinding, automatic tension controller and magnetic powder brake for unwinding tension control
5. Double cam shaft for rewinding, Magnetic clutch control for rewinding tension control
6. Main motor with frequency converter for speed regulation
7. Equipped with rim charge conveying device.
8. Automatic meter counting device.
Main Technical Parameters:
| Model | LFQ-700B |
LFQ-1100B |
LFQ-1300B |
| Max. Width of Mother Roll | 700mm |
1100mm |
1300mm |
| Max. Diameter of Mother Roll | Φ 600mm |
Φ 600mm |
Φ 600mm |
| Width of Final Roll | 30-600mm |
30-600mm |
30-600mm |
| Slitting and Rewinging Speed | 5-160m/min |
5-160m/min |
5-160m/min |
| Tolerance of EPC | < ± 0.5mm |
< ± 0.5mm |
< ± 0.5mm |
| Total Power | 2.7kw |
3.5kw |
3.5kw |
| Weight of Machine | 1200kg |
1500kg |
1800kg |
| Overall Dimension | 2.0× 1.1× 1.4m |
2.4× 1.3× 1.4m |
2.6× 1.5× 1.4m |
