Specifications
Film Folding MachinePP, OPP single-layer film folding machine
options: EPC web guider, ultrasonic sealer
Film Folding Machine
PP film folding machine
OPP film folding machine
Summary:
This film folding machine is used for folding the single-layer sheet PP OPP film and then rewinding, which is an assistant equipment of the bag sealing and cutting machine for making garment bag, sock bag, towel bag, bread bag, ornament bag, underwear bag, stationary bag, electric element bag, bamboo article and wooden products bag etc. plastic packing bags.
* It equips with bottom-gusset device, adhesive tape inserting device, pearly-lustre film inserting device.
Optional Devices:
- Ultrasonic Sealing Device
- EPC web guider device (film edge position control) including guider controller, guider motor, double sets of photocells, and magnetic powder tension controller.
Main Technical Parameters:
Model |
TR-ZB1200 |
TR-ZB1400 |
TR-ZB1600 |
Max. Width of Raw Material |
1200mm |
1400mm |
1600mm |
Max. Diameter of Raw Material |
Φ600mm |
||
Production Speed |
10-60m/min |
10-60m/min |
10-60m/min |
Max. Diameter of Finished Product |
Φ600mm |
||
Total Power |
2kw |
3kw |
3.5kw |
Machine Weight |
500kg |
600kg |
800kg |
Machine Dimension |
2.7×1.3×1.7m |
2.9×1.3×1.7m |
3.1×1.3×1.7m |
Working Voltage |
380V 3-phase 50Hz |
||
