industrial wood drying machine equipment
Brife introduction of wood drying machine equipment:
wood drying machine is widely used to dry wood sawdust, wood chips, rice husk, sugar cane bagasse, etc. which is the pre-processing for making pellet, briquette, biomass fuel, etc.
There is a screw conveyor designed for feeding the material, thus saving much labor.
Structure of wood drying machine equipment:
♣ Fireplace is the place where the firewood, coal, gas or other material is burning for heat, there is a specially designed buffer which can make the hot air through but provent the fire in.
♣ Inlet place is beside the fireplace, thus the material can be dry at a early time.
♣ Roller is running evenly to make the material drying and processing at the same time.
♣ Discharging unit is installed with thermeter to control drying temperature. The temperature change of dryer's feeding end can be indicated by the thermometer to control the inner drier temperature ( generally 250-350°C)
♣ The cyclone is for the discharging, whcih is more convenient and air lock for making the discharging little noise and no waste.
Technical parameter of wood drying machine equipment:
Model |
BD-GT650 |
BD-GT800 |
BD-GT1000 |
BD-GT1200 |
BD-GT1500 |
Capacity kg/h |
600-800 |
800-1000 |
1200-1500 |
1500-2000 |
2000-2500 |
Main Power |
5.5kw |
7.5kw |
7.5kw |
11kw |
15kw |
Air lock power |
1.1kw |
1.5kw |
2.2kw |
2.2kw |
2.2kw |
Weight |
2600kg |
2800kg |
3800kg |
4500kg |
5000kg |
Diameter of roller |
0.68m |
0.8m |
1m |
1.2m |
1.5m |
Length of roller |
9m |
10m |
10m |
10m |
10m |
Pictures : whole look of the wood drying machine equipment.
If you want to know more about the machine, please don't hesitate to contact me. I am pleased to show you all the details.
