China High Quality PF Fine Crusher

China High Quality PF Fine Crusher photo-1
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Impact Crusher
Capacity(t/h):
50-80
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Impact Crusher
Capacity(t/h) 50-80
Place of Origin Henan, China
Brand Name he nan zhongcheng machinery
Model Number PF-1010

Specifications

1Deep broken cavity
2Large crushing ratio
3high crushing efficiency
4Through ISO9001:2000
5Low noise and less dust

 China high quality PF fine crusher





 1. Introduction

fine crusher is that the ore is put into the feeding opening and sliding downward along the plate; the ore will be smashed by the high-speed rotary hammer on the rotor when the screen ores are in the falling process. And with high speed along the tangent direction back toward to the first plate, continues to break the ore, the back plate will hit the ore back, then collide with other ores. Therefore the ore was crushed by the repeated impact in the first cavity, Some of the ore in the first chamber will be broken to a certain particle size, they through from the gap between the bake plate and the rotor will be put into the second broken cavity, continue to be crushed, until they change into the small size and then come out through the bottom of the crusher.

China high quality PF fine crusher

2.Impact crusher’s features:

1. Large crushing ratio and high crushing efficiency

2. Low production costs and less power consumption

3. Small size and light weight

4. Cubic shape of product, adjustable output size

3.fine crusher main technical parameters:

China high quality PF fine crusher

Type

Specification

(mm)

Input size

(mm)

Max feed size

(mm)

Capacity

(t/h)

Motor power

(kw)

PF-0607

Ø-644×740

320×770

100

10-20

30

PF-0807

Ø-850×700

400×730

300

15-30

30-45

PF-1008

Ø-1000×800

400×830

300

30-50

37-55

PF-1010

Ø-1000×1050

400×1080

350

50-80

55-75

PF-1210

Ø-1250×1050

400×1080

350

70-120

110-132

PF-1212

Ø-1250×1250

400×1300

350

100-150

132-160

PF-1214

Ø-1250×1400

400×1430

400

130-180

160-200

PF-1315

Ø-1320×1500

860×1520

500

160-250

180-260

PF-1320

Ø-1320×2000

860×2030

500

300-350

300-375

China high quality PF fine crusher

Note: for information purposes only, any questions please contact us!
