Specifications
1. High crushing efficiency2. Large crushing ratio
3. Less power consumption
4. Low production costs
2013 Good quality Fine Impact Crusher machine with PFX Series
This series of crushers has been developed and improved by incorporating the advantages of the technology both home and abroad so that the structural design is further optimized. Uses in all kinds of medium degree hardness solid material, cement industry for crushing limestone, paste, chamotte, mix material and so on. Also may be used for fine crushing the calcium phosphide, the dolomite, and pearl ore and so on. It can be widely used in the building materials, the chemical fertilizer, mining industry sector and fire-proof material and so on.
1.Working principles of high-efficient fine impact crusher:
This equipment adopts two motors, which take two rollers to rotate reversely by the decelerator. When the materials drop on the rollers through the charge hole under the friction of the rollers, they are dragged between the two rollers, grinded by the roller's crushing; the grinded materials are pushed prefatorily by the rollers.
2.Features of high-efficient fine impact crusher:
1. Small and uniform particle size
2. Large capacity, hammer, long life
3. Supporting smaller power
4. Simple process and structure, easy maintenance, smooth operation
3.High-efficient fine crusher's main technical parameters:
Type |
Material-in size(mm) |
Material-out size(mm) |
Yield(t/h) |
Power(kw) |
Weight(t) |
PFX800×300 |
<=60 |
<=5(96%) |
20-25 |
37 |
2.5 |
PFX800×600 |
<=60 |
<=5(94%) |
35-50 |
45 |
4.7 |
PFX800×800 |
<=70 |
<=5(92%) |
40-60 |
75 |
6.5 |
PFX1000×1000 |
<=80 |
<=5(91%) |
60-90 |
90 |
8.8 |
PFX1000×1200 |
<=90 |
<=5(88%) |
75-110 |
110 |
13.6 |
PFX1300×1200 |
<=100 |
<=5(86%) |
120-145 |
160 |
19.5 |
PFX1300×1400 |
<=120 |
<=5(85%) |
145-180 |
180 |
26 |
