Hydraulic Shoe Making Machine
Detailed Product Description
Suitable for the cutting of leather, sponge, nylon, textile, plastic materials, cardboard and synthetic materials.
Application:
1) This machine is suitable for the cutting of plastic materials, leather, sponge, nylon, textile, cardboard and synthetic materials;
2) It can cut one or several layers of sheet materials.
Features:
1. It cuts economically & safely, at a high speed & low noise.
2. The rapid pressing of the working board turns into smooth cutting at down to the blade, which ensures accuracy between layers.
3. Exclusive setting structure with trimming device makes the best cutting setting of height and depth, and prolongs working life of the cutting knife and cutting board.
4. Central automatic lubricate system in principal axis to ensure the machining precise and improve its durability.
Technic Specification:
| Name |
Hydraulic shoe making feeding machine
|
||
| Model | XCLL2-250 | XCLL2-350 | XCLL2-500 |
| Max cutting force | 250KN | 350KN | 500KN |
| Cutting speed | 0.2m/s | 0.2m/s | 0.2m/s |
| Sway arm width | 10-100mm | 10-140mm | 10-140mm |
| Effective length | 50-150mm | 50-150mm | 50-150mm |
| Main motor power | 2.2Kw | 4Kw | 5.5Kw |
| Dimession of the plane(length×width) | 1620×500mm | 1620×650mm | 1620×800mm |
| Space size | 1880×700×1600mm | 2050×760×1650mm | 2250×900×1700mm |
| Tolal weight | 1500Kg | 2800Kg | 4000Kg |
| Energy power | 380V 50Hz | 380V 50Hz | 380V 50Hz |
| Oil tank capacity | 70L | 90L | 130L |
