Product Image
Linning process is SBMC’s factory Patent.
Pump casing and cover are made of HT200 iron lining with PFA, PTFE, impeller made by WCB wrapped by PTFA, PTFE, which grantee this type centrifugal pump could widely used in corrosive application and wear well.
Reliable mechanical seal
Shaft seal is outside seal, stationary seal is alumina ceramic ( 99.9%), rotating seal is PTFE filling material or according to customer request.
Advantage: High corrosive, well leakproof, easy assembly and maintenance
Standard
- ISO2858, DIN EN 22858.
Characteristic analysis
0.1 Impeller Patent advantage
| Patent no. | The name of the patent | The patent type | Available Date |
| ZL200820038733.4 | Corrosive resistance lined impeller | The patent for utility model | 08/Aug./2008-07/Aug./2018 |
Closed impeller with flow-optimized vane channels: for high efficiency and low NPSH values.
The metal core is protected by a thick-walled seamless plastic lining, the large metal core can increase the mechanical strength considerably even at elevated temperature and high flow rates
0.2 Material advantage
- Qualified Virgin Fluoroplastic
PTFE, FEP, PFA are qualified large manufacture production, safe and secure plastic , has good stability, safety and environmental protection. Please ease of use
- Bearing: NSK, SKF or local qualified brand.
Product Parameters
| Item | Model | Flow | Pump | Efficiency | NPSHa | Inlet*Outlet | Power (kw) | Pump &Motor Weight | ||||
| (m3/h) | head | % | (m) | (kg) | ||||||||
| 1 | IHF25-20-125 | 2 | 20.5 | 25 | 3 | 1.1 | 75 | |||||
| *3.2 | 20 | 32 | 25*20 | |||||||||
| 5.5 | 18 | 46 | ||||||||||
| 2 | IHF25-20-250 | 2 | 80 | 12 | 2.5 | 25*20 | 7.5 | 225 | ||||
| *3.6 | 80 | 18 | ||||||||||
| 5.5 | 78 | 26 | ||||||||||
| 3 | IHF32-20-125 | 2 | 20.5 | 25 | 3 | 32*20 | 1.1 | 75 | ||||
| *3.2 | 20 | 30 | ||||||||||
| 5.5 | 18 | 46 | ||||||||||
| 4 | IHF40-25-125 | *6.3 | 20 | 30 | 2.5 | 40*25 | 1.5 | 75 | ||||
| 8 | 20 | 31 | ||||||||||
| 10 | 18 | 32 | ||||||||||
| 5 | IHF40-25-160 | *6.3 | 32 | 30 | 3 | 40*25 | 3 | 124 | ||||
| 8 | 32 | 31 | ||||||||||
| 10 | 30 | 32 | ||||||||||
| 6 | IHF40-25-200 | *6.3 | 50 | 20 | 3 | 40*25 | 5.5 | 170 | ||||
| 8 | 50 | 23 | ||||||||||
| 10 | 48 | 30 | ||||||||||
| 7 | IHF40-32-250 | *6.3 | 80 | 20 | 5 | 40*32 | 11 | 255 | ||||
| 8 | 80 | 24 | ||||||||||
| 12 | 78 | 34 | ||||||||||
| 8 | IHF50-32-125 | 7 | 22 | 47 | 3.2 | 50*32 | 2.2 | 110 | ||||
| *12.5 | 20 | 52 | ||||||||||
| 15 | 16 | 50 | ||||||||||
| 9 | IHF50-32-160 | 7 | 33 | 35 | 3.2 | 50*32 | 4 | 135 | ||||
| *12.5 | 32 | 47 | ||||||||||
| 15 | 30 | 47 | ||||||||||
| 10 | IHF50-32-200 | 7 | 51 | 28 | 3.2 | 50*32 | 7.5 | 180 | ||||
| *12.5 | 50 | 40 | ||||||||||
| 15 | 49 | 48 | ||||||||||
| 11 | IHF50-32-250 | 7 | 80 | 21 | 5 | 50*32 | 11 | 255 | ||||
| *12.5 | 80 | 34 | ||||||||||
| 15 | 77 | 38 | ||||||||||
| 12 | IHF65-50-125 | 15 | 22 | 46 | 3.5 | 65*50 | 3 | 135 | ||||
| *25 | 20 | 61 | ||||||||||
| 35 | 16 | 67 | ||||||||||
| 13 | IHF65-50-160 | 15 | 33 | 45 | 3.5 | 65*50 | 5.5 | 155 | ||||
| *25 | 32 | 56 | ||||||||||
| 35 | 30 | 65 | ||||||||||
| 14 | IHF65-40-200 | 15 | 52 | 35 | 3.5 | 65*40 | 11 | 210 | ||||
| *25 | 50 | 51 | ||||||||||
| 35 | 46 | 48 | ||||||||||
| 15 | IHF65-40-250 | 15 | 82 | 33 | 3.5 | 65*40 | 18.5 | 360 | ||||
| *25 | 80 | 48 | ||||||||||
| 35 | 72 | 50 | ||||||||||
| 16 | IHF80-65-125 | 35 | 22 | 52 | 4 | 80*65 | 5.5 | 195 | ||||
| *50 | 20 | 65 | ||||||||||
| 60 | 18 | 70 | ||||||||||
| 17 | IHF80-65-160 | 35 | 33 | 60 | 4 | 80*65 | 11 | 228 | ||||
| *50 | 32 | 64 | ||||||||||
| 60 | 27 | 53 | ||||||||||
| 18 | IHF80-50-200 | 35 | 52 | 55 | 4 | 80*50 | 15 | 250 | ||||
| *50 | 50 | 63 | ||||||||||
| 60 | 45 | 55 | ||||||||||
| 19 | IHF80-50-250 | 35 | 82 | 48 | 4.5 | 80*50 | 30 | 480 | ||||
| *50 | 80 | 56 | ||||||||||
| 60 | 72 | 50 | ||||||||||
| 20 | IHF100-80-125 | 65 | 22 | 62 | 4.5 | 100*80 | 11 | 245 | ||||
| *100 | 20 | 65 | ||||||||||
| 120 | 17 | 68 | ||||||||||
| 21 | IHF100-80-160 | 65 | 35 | 65 | 5 | 100*80 | 15 | 250 | ||||
| *100 | 32 | 70 | ||||||||||
| 110 | 26 | 65 | ||||||||||
| 22 | IHF100-65-200 | 65 | 51 | 62 | 5 | 100*65 | 30 | 480 | ||||
| *100 | 50 | 68 | ||||||||||
| 120 | 43 | 56 | ||||||||||
| 23 | IHF100-65-250 | 65 | 82 | 60 | 5 | 100*65 | 45 | 550 | ||||
| *100 | 80 | 65 | ||||||||||
| 120 | 65 | 70 | ||||||||||
| 24 | IHF125-80-160 | 100 | 38 | 57 | 5 | 125*80 | 30 | 460 | ||||
| *160 | 32 | 64 | ||||||||||
| 180 | 26 | 52 | ||||||||||
| 25 | IHF125-100-200 | 120 | 55 | 63 | 6 | 125*100 | 55 | 660 | ||||
| *200 | 50 | 65 | ||||||||||
| 220 | 45 | 62 | ||||||||||
| 26 | IHF125-100-250 | 120 | 86 | 54 | 6 | 125*100 | 75 | 850 | ||||
| *200 | 80 | 68 | ||||||||||
| 210 | 65 | 61 | ||||||||||
Note:
-item marked with”*”for standard parameter
Sectional Drawing
Materials of Construction
The Pump's inlet diameter <150mm
Item |
Designation |
Material |
1 |
Pump housing |
Cast iron HT200 with FEP/ PFA |
2 |
Impeller |
FEP fused with PTFE / PFA |
3 |
Seal ring |
Fluorubber |
4 |
Pump cover |
Cast iron HT200 with FEP/ PFA |
5 |
Mechanical seal cover |
SUS321 stainless steel |
6 |
Mechanical seal |
Silicon carbide ,hard alloy |
7 |
Bearing box |
Cast iron HT200 with F46 |
8 |
Pump shaft |
45# Steel |
OEM
Factory Basic Information:
- Established in 1985, 30 years history
- Land area: 100,000m2, 2 factory division for chemical process pump production
- 1 precison foundry
- 20 Engineers R&D
Advantages
- Reserch & Development: SBMC factory have a total of 20 engineer research and development team, which gives it distinct advantages in terms of product and technology upgrading.
- Law Material Purchase:
- 28 years raw material purchasing experience
- Fully integrated supply chain
- High quality and affordable purcha sing cost
- High supplier quality management
- Quality : ISO9001 Quality Management System
Company Show
Since from 1985, focus on magnetic drive pump and Teflon lined process pump manufacturing .
Production Process
Strictly Compliant with ISO9001 standard
Robust Service Team
Patent Certificate / Certification LOGO
Our Clients
Packaging Transportation Process
FAQ
Can you supply pump qualified with ANSI and ASME standard?Yes, our pump compliant with ISO / ASME/ANSI standard.
How can I purchase order without seeing the quality first?If it is a big order, we can provide a sample for running testing at your plant. And you can see the below our customers photos and more project reference list on.
How do you control the quality of the products?Our production is strictly according to ISO 9001 standard and factory was established in 1985, have 30 years experience in Teflon lined chemical process pumps, valves, piping and fittings.
How to customize pumps and mechanical seals ?Customers could send us application data, we will select suitable pump and seal types, or client could send us drawings, We are well in OEM and ODM.
How can I pay for my items? What is the payment you can provide?Usually by T/T, 30% down payment once PI confirmed, the balance will be paid after inspection and before shipment.
L/C at sight
1 year for main construction warranty.
How long is production lead time?Normally 25 days. If client need urgently, we have a huge spare parts stock, we could finish assembly and testing in 7-15 days.
What is the shipping terms you can provide ?Depnends on customer's requirements, we can provide different transportantin terms, such as EXW, FOB, CIF.
Who is in charge of after-sales?Inside sales. It can save customer's time and high efficiency communicate. Shuangbao has professional after sales service team, we will follow up the client's comments and suggest them good solutions. Solve client's problems and keeping the clients profit.
Who is in charge of maintenance?Local agent. Client is first, if pump running has any problem on site, our local agent will arrival the plant within 24 hours.
