Specifications
Brand New Headphone AMP Matrix CUBEInput: Optical ,BNC,USB ,
One year warranty,high quality ,HiFi products
NEW VERSION Matrix CUBE Headphone Amplifier
Features:
All the following features enable CUBE to explore every small detail in the music for you ,and provide you a tactile sensation of its sound performance ,with its ultra-high resolution and signal-to-noise ratio, to fully meet your demands for a high-quality Hi-Fi.
1.Top 24Bit/192KHz D/A converting units,WM8740 of Wolfson.
2.High-end T1 digital Sampling Rate Increase processing chip-SRC4382.
3.ASRC(Asynchronous Sample Rate Converter) the technique of separating the internal and external clock and resampling, which effectively reduces the timing jitter generated by the former sources and transmission lines.
4.A professional digital receiver chip of ultra-low jitter and a high-precision clock independent system clock.
5.USB,OPTICAL,and coaxial digital signal input modes,and a coaxial output.
6.Up to 24BIT/192KHz digital signal input.
7.ASRC Sampling Rate can be increased to 174.6KHz/192KHz and putout through digital channel.
8.Its internal headphone amp unit can easily drive any headphones of 300 ohms and below.
9.Headphone amplifier can work independently when it is connected to external signal.
10.A professional stereo OP-Amp,OPA2134/LM833, to provide you with the best signal playback effect.
11.Its internal circuit units adopt the multi-stage stabilized voltage supply respectively.
Parameter:
Digital interface
| Input | |
| Optical |
Sealed optical input Sampling Rate:32KHz-192KHz |
| BNC |
Standard BNC 75ohm Sampling Rate: 32KHz-192KHz |
| USB |
Standard USB Connector Sampling Rate:44.1KHz-48KHz |
| Output | |
| Coaxial Output |
RCA jack Sampling Rate:32KHz-192KHz Supports AC-3 |
| DTS data output Output Level | 0.5Vp-p(75ohm) |
Analog Interface:
| RCA Output Level | 2.0VRMS |
| RCA Input Impedance | 47k Ω |
| Frequency Response | 20Hz-20KHz |
| SNR | 109dB |
| Dynamic Range | 107dB |
| Distortion | < 0.0005%(1KHz) |
| Power Requirements |
AC 220V 50/60Hz AC 110V 50/60Hz |
| Power Consumption | < 15w |
Other Specification:
| Operating Temperature | 0-+40°C |
| Weight | 1.1KG |
| Dimension | 160*145*44mm |
Packing Detail:
Power Cable X1
User Guide X1
BNC/RCA Adaptor X1
