Home > Consumer Electronics > Audio & Sets > Amplifier > Matrix Mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote

Matrix Mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote

Matrix Mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Matrix
Model Number:
mini-i 24/192
Type:
Home Amplifier
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Matrix
Model Number mini-i 24/192
Type Home Amplifier
Channels 3 (2.1)

Specifications

Matrix mini-i 24/192 Balanced USB DAC& Head AMP &Remote
Full balanced stereo design.
Designed and fine tuned for audiophile

Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp







Product Description:





Featrues:



          D/A DAC chip AD1955 x 2

          Full balanced stereo design

          Up to 24Bit/192kHz sampling

          USB input works with Windows 2000/XP/Vista/7, Linux and Mac OS 10.x, no extra driver needed

          Pre-Amp/HP-Amp and Pure DAC modes switchable

          Low jitter receiver chips and separate clock

          Built-in headphone amplifier, for up to 300 ohm headphones

          OP275/OPA2134 opamps NOT replaceable

          Balanced/Unbalanced outputs

          Various inputs: BNC/RCA/Toslink/AES/EBU/USB

          Large screen LCD display

          Designed and fine tuned for audiophile

          Digital input pass-through via an RCA output, easy connect to another receiver





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote





Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote



Matrix mini-i 24/192 Balanced USB DAC & Headphone Amp&Remote



Parameter:



Digital Input

Optical: toslink, 32-192kHz
Coaxial: 75 ohm RCA/BNC, 32-192kHz

USB: USB-B, 44.1-48kHz
AES/EBU: Standard XLR balanced, 32-192kHz

Digital Output
Coaxial RCA
32-192kHz
Support AC3/DTS Pass Through
Analog Interface
RCA/XLR
Frequency Response: 20-20kHz
Signal to Noise Ratio: 105dB
Dynamic Range: 108dB
Distortion 0.0002% (1kHz)
Power Support  AC 100-120V / 220-240V(Please specify)
Front Panel Color Silver
Case Color Black/Silver (Please specify)
Weight 2 kg
Size 205 x 155 x 48mm





Packing Detail:



         Matrix mini-i DAC x 1

     Power cable x 1

     USB cable x 1

     BNC/RCA converter x 1

     Remote Control  x1
