MUSILAND SV DAC05 DAC DIGITAL STEREO 24/192 Audio DACQuality assurance, one year warranty
Color: Black
MUSILAND SV DAC05 DAC DIGITAL STEREO 24/192 Audio DAC
Product:
SVDAC05 is Musiland's third generation of high performance stereo audio decoder products.It is launched to face the computer multimedia applications and high -fidelity music users,possessing many excellent features.
1, electronic control interface
SVDAC05 used advanced microcomputer control technology, providing the users with hunmanized push-button operation interface and digital display interface, can real-time display the input signal sampling frequency and the current output volume, can choose the input methods conveniently, adjust output volume,all user settings can automatically save.
2, high quality high specification characteristics
SVDAC05 used CIRRUS's top digital/analog concersion chip CS4398, its up to 120dB SNR and dynamic range parameter provides extremely high decoding performance and perfectly support up to 24 bit/192 KHz high specifications decoding.
Analog output used Musiland's original balanced simulation filter circuit,which possess both HI-FI output features and good Musicality.
The built-in high-performance headphone amplifier circuit,can promote low impedance and high sensitivity headphones.
3,variety of input and output ports
SVDAC05 has optical ,RCA coaxial,BNC coaxial input port, which can connect digital audio equipment more flexible.
Special disigned USB input port can connect computer system as an independent USB sound card equipment.
Analog output with RCA lines and 3.5 mm headphone output port can easily connect amplifier and headphones system.
Pictures:
parameter:
| Dynamic range | 120dB |
| Signal-to-noise ratio (A) | 120dB projects |
| Total harmonic distortion | 0.0005% |
| Frequency response (20Hz ~ 20KHz) | + - 0.5 dB |
| Output level | 3V RMS |
| Output impedance | Ω 10K |
| Headphone output power | 500mW/RL = 100 Ω, Ω 200mW/RL = 32 |
| The ac power input specification | 220V (otherwise 120, 240V optional), 50/60Hz |
| Power | 15W acuities |
| Product color | black |
| Weight | 1.5KG |
| Size | 210*160*50 mm |
Packing detail:
power line x 1
optical cable x 1
USB cable x 1
use manual x 1
warranty card x 1
