Topping TP-D2 Portable Head AMP & USB DAC & Sound Card

Topping TP-D2 Portable Head AMP & USB DAC & Sound Card photo-1
US$ 108 - 127 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
Topping
Model Number:
TP-D2
Type:
Professional Amplifier
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Topping
Model Number TP-D2
Type Professional Amplifier
Channels 2 (2.0)

Specifications

support Analog signal,Digital coaxial signal,Digital optical signal,USB signal
Multifunction DAC Hi-Fi DAC&AMP

Topping TP-D2 Portable Head AMP & USB DAC & sound card





Product:



TP60 is a company used by the U.S. TRIPATH DIGITAL POWER PROCESSING (DPP) technology, high-power Class T digital amplifier. From the beginning of the year 2009 in mid-2010, TP60 gone through the development and debugging time more than a year, a total of eight versions of the development of PCB, 3 different layouts and structures. Eventually arrived at the perfect retail version now.


TP60 has two analog inputs, use the touch panel switch to switch, and status light will indicate the current state of the power amplifier.



This is a our unique features.

TP60 in 4 European impedance output power up to 80W * 2. 8 Europe impedance output 50W * 2 still can be power.





Topping TP-D2 Portable Head AMP & USB DAC & sound card NEW



TP-D2 is a new generation multi-function extension product decoder, the decoder sets coaxial, fiber optic decoder, USB external sound card and headphone amplifier as one; in the small of the volume, can be used as multi-channel headphone amplifier input, multi- the first amplifier input, or input of the all-around multi-decoder to use, the use of very wide scope.

D2 appearance concise fashion, the internal use of good design, the industry's leading chip-scale high fidelity sound quality HIFI device to your computer, digital players, DVD players and other products widely Lyrics value perfect sound quality.







D2 features:

1, supports up to 4 types of input signals: analog, digital coaxial signal, digital optical signals and USB signals, covering all the common signal;

2, support a wide range. Consistent with PCM formats, including 44.1kHz, 48kHz, 88.2kHz, 96kHz, 16bit to 24bit range of coaxial and optical digital digital signal can be the perfect support;

3, with double line and headphone output to connect to other devices, headphone output can drive headphones of 32 Euro to 600 Euro;

4, built-in USB chips, can be used as high-fidelity external sound card to replace the original sound card using the computer;

5, aluminum chassis using CNC machining centers precision machining, CNC machined with solid knobs, giving you superior visual impact and operation of hand.





Topping TP-D2 Portable Head AMP & USB DAC & sound card



D2 use aluminum case




 Topping TP-D2 Portable Head AMP & USB DAC & sound card





D2 ring light is soft and stylish







Topping TP-D2 Portable Head AMP & USB DAC & sound card



D2 inner







Topping TP-D2 Portable Head AMP & USB DAC & sound card





D2 input port: analog, coaxial, optic, USB









Topping TP-D2 Portable Head AMP & USB DAC & sound card







Topping TP-D2 Portable Head AMP & USB DAC & sound card

 Topping TP-D2 Portable Head AMP & USB DAC & sound card







package: D2 unit,  power adapter, USB cable, Manual, 6.35 to 3.5 Adapter.





 Topping TP-D2 Portable Head AMP & USB DAC & sound card







D2 headphone amp using OP + BUF structure, BUF fever by Toshiba C3421 + A1358 as the tube.




Topping TP-D2 Portable Head AMP & USB DAC & sound card









Topping TP-D2 Portable Head AMP & USB DAC & sound card





D2's power supply. In order to ensure pristine sound quality, D2 analog part and digital part of the isolated power supply to the regulator device is ON Semiconductor (formerly Motorola) the LDO regulator.







Topping TP-D2 Portable Head AMP & USB DAC & sound card





D2 decoding used by the U.S. ADI's 24bit decoder chip AD1852JRS.







Topping TP-D2 Portable Head AMP & USB DAC & sound card

D2 uses high-precision metal film resistors Japanese KOA D2 helps to provide high stability, low bias, low distortion of the working conditions.







Topping TP-D2 Portable Head AMP & USB DAC & sound card





nichicon,MUSE BP







Topping TP-D2 Portable Head AMP & USB DAC & sound card



ALPS







Technical Specifications:





Decoder part :



Line out Output signal strength 1.85Vrms
Distortion <0.0025%
Frequency response 20-20000Hz ± 0.3dB
Output Impedance 200Ω



Headphone Amplifier parts:



Output power 123mW 10% THD + N (32Ω)
Distortion <0.0028% @ 75mW (32Ω); <0.0027% @ 54mW (300Ω)
Frequency response 20-20000Hz ± 0.3dB
Input Sensitivity 1.5V
