Plastic wire drawing machine
Uses and Features
LGSJ-65-80-90 Plastic wire drawing machine production line is special equipment use PE or PP as raw materials to produce round wire. Replacement of mold or other auxiliary equipment also can produce other plastic products. Stability and mechanical properties of the unit, using the latest high quality and efficient screw, a strong extrusion, high output, torque, plasticizing effect is good; machine with automatic temperature control system, production and product uniformity and stability, and operation procedures simple. Drawing class can be added or use recycled materials production and processing. according to user needs, with automatic loading and materials, automatic drying hopper. The unit is a rope, nets and other products ideal for production equipment, with long hours also produces monofilament yarn machine.
Production name |
number |
overall dimensions(mm) |
notes |
Wight (KG) |
|
extrudor
|
A set |
2980*880*1750 |
Hardened reducer one set Screw set, diameter 65-80-90mm, aspect ratio 28:1, materials 38CrMoAl nitrogen treatment Host transmission power 15-18.5-30KW, heating power 16-20-25KW, motor adopts frequency control Using quartz tube heating ring, stainless steel spinneret 5 pieces, 60/80/100/120/140,production capacity: 30-50,40-60,50-70kg/h |
1000 |
First drawing machine |
A set |
1300*950*1300 |
5 roller extension, rubber roller 2, the steel roller 5, the electrical power 1.1-1.5-2.2kw, frequency speed control |
700 |
Heat sink |
A set |
3000*300*1300 |
Use of electric heating pipe, heating power of 13-15-18kw, heat sink length of 3 meters, material stainless steel |
240 |
Second drawing machine |
A set |
1600*950*1300 |
5 roller extension, rubber roller 2, the steel roller 5, the electrical power of 4-5.5-7.5kw, frequency speed regulation, the drafting multiple of 5-12 times |
800 |
winding |
A set |
2800*980*1690 |
station winding, motor power 3-4-5.5kw |
500 |
Distribution |
A set |
1600*500*800 |
And drawing machine supporting |
80 |
Bobbin |
20 Parts |
Diameter 250*length 300 |
|
240 |
