Plastic PP Round Wire Rope Making Machine
1. LGSJ65/28 extruder
Center height 1000mm
Screw speed 0~ 70 rev / min
1.1 Gear box
Hardened Jiangsu International
Reducer Model ZLYJ146
1.2 Screw barrel parameters
Screw diameter Φ65mm
Screw diameter ratio 28 / 1
Screw material 38CrMoAlA
Screw structure Mixing screw-type structure
Heat treatment Nitriding heat treatment
Surface hardness HV940 ~ 1050
Nitriding depth 0.6 ~ 0.7mm
1.3 barrel heating and cooling parameters
Barrel heating infrared heater 3 section 15KW
1.4 Main motor parameters
Speed mode frequency control mode
Motor power 15kw
1.5 Electric Control
Temperature control table intelligent digital
Low-voltage electrical Chint
- 2. Extrusion die
Vertical porous 40-120 pieces
3. Frist Traction machine
Roller length 200mm
Motor Model Y90L-4
Motor Power 1.5kw
Speed adjustment mode frequency control mode
4. Heating water tank
Heating power 8kw
Water tank stainless steel
Water tank length 3000mm
5. Tractor
Motor Model Y112M-4
Motor Power 5.5kw
Speed adjustment mode frequency control mode
6. Ten-position double-sided friction winder
Motor Model 10N-4
Motor Power 3kw
Speed adjustment mode torque control mode
7. Summary
Production capacity 30-50kg / h
Three phase supply 380V 50HZ 48KW
