1L Full-automatic plastic blow molding machine
Performance and characteristics:
It mactched with the computer control,frequency conversion.Nitriding screw cylinder matched with the mixing head.With the tectorial nose,the production of double-layer plastic bucket(bottle),can be with the liquid location line,also can two bottles (4 bottles) of one-mode.
Production capacity:180-240 mold/hour
Product application:
It’s mainly used in a variety of engine oil bottle,drug bottle,fruit juices and feeding-bottle for 1 liter or less.
Technical parameters:
Large capacity that blow molding the most |
1L |
The template size(W×H) |
300×200mm |
Clamping force |
20KN |
Min. mould thickness |
100mm |
Max. space between platens |
300mm |
Host computer screw diameter |
45mm |
Screw L/D ratio |
25:1 |
One pair of machines screw diameter |
25mm |
Screw L/D ratio |
30:1 |
Liquid location line screw diameter |
25mm |
Screw L/D ratio |
25:1 |
Screw speed |
20-60rpm |
Max. plasticating capacity(PE) |
25kg |
The electrial machinery merit rate |
5.5KW |
Extruder driving power |
4KW |
Heating power |
10KW |
Number of barrel zone |
9 |
The machine weight(T) |
2200kg |
The mould size outside(L×W×H) |
2×1.2×2m |
