Help CenterJCX Ridge Roll Forming Machine Roof Tile Roll Forming
Related Products
-
Metal Roof Ridge Cap Roll Forming MachineUS$ 13,500 - 19,500MOQ: 1 Set -
Metal Roof Ridge Cap Roll Forming MachineUS$ 13,500 - 19,500MOQ: 1 Set
-
7.5 Kw Tile Roof Ridge Cap Roll Forming Machine With 0.3 - 0.7mm Material ThicknessUS$ 11,500 - 19,500MOQ: 1 Set
-
7.5 Kw, 0 - 15 M/min Hydraulic Cutting Ridge Tile Roll Forming Machine for Roof Ridge CapUS$ 11,500 - 19,500MOQ: 1 Set
-
Hydraulic Cutting Roof Ridge Cap Roll Forming Machine With PLC Control SystemUS$ 11,500 - 19,500MOQ: 1 Set
312 ridge cap roll forming machine, roof panel sheet machines for sale,roof panel steel machinery china
Details of ridge tile roll forming machine as follows:
1. General performance of the line
1) Material thickness: 0.3-0.8mm
2) Material width: max 1250mm
3) controlling device:PLC
4) Line speed:2-4 m/min
5) Power supply: 380V/ 50Hz/ 3Phase or customer design
6) Total power: 4+3 kw
7) Dimension: about 7.2m*1.4m*1.5m
8) Feeding width: 500mm
9) Number of forming stations: 13-15 pairs
2. Working flow
1) Decoiling: feeding of the material for bottom metal strip.
2) Roll forming: producing the bottom metal strip for roof or wall panel.
3) Raw material feeding table: In order to feeding the mmaterial straightly.
4) Main forming station: shaft material is 45# steel forged,roller material is 45# bearing steel.
5) Cutting system: material of the cutting blade is Cr12MoV,the best cutting distance of the blade is within 1mm.
6) Controlling system: All the production line will controlled by the PLC,realized the full- automatic.
7) The counter: every machine we will provided several extra counters for the damage of the counter.
8) Run-out table:we have different kinds of receiving table,the simple one,the auto-stacker or other designed run out table,we can designed it according your demand.
9) We will provided a whole production line if you have no special requests.
The production of ridge tile roll forming machine:
Our machine advantage:
Our customers:
Procurement Aspects
Procurement Aspects | Detailed Rule |
Payment Terms | The payment shall be made by L/C or T/T ( 30% down-payment and the balance for 70% shall be paid before container loading at the seller`s factory when the buyer confirms the quality is up to the contracted requirements. |
packaging | Suitable for sea transportation.Usually one High precision Grape stake roller formed facility loads in one container.Depends on the machine's size and weight. |
Delivery Time | 30-65days. Depends on the machine type. |
After-sales Service | Warranty: 1 year warranty from date of shipment. |
Purchasing Process | fistly, send us the product profile. If it needs punching, please also send us the drawing of holes. sixthly, according to the contract, you pay the money and we ship the machine to you. |
If you are tired of those Chinese bad machines, and want to buy high quality machines in China, Just stop searching!we are your best choice!We offer you quality machine with good price!
Contact Person:presley.xu
Skype:Presley.xu
Mob:+86 18732755439
