Help CenterRoof and Wall Steel Roll Forming Machine
Related Products
-
Double Layer Roll Forming MachineUS$ 8,000 - 14,000MOQ: 1 Set -
Double Layer Roll Forming MachineUS$ 8,000 - 14,000MOQ: 1 Set
-
312 Ridge Cap Roll Forming MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Boltless Type Roll Forming MachineUS$ 10,000 - 40,000MOQ: 1 Set
-
Square Downpipe Forming MachineUS$ 10,000 - 18,000MOQ: 1 Set
Specifications
roof and wall roll forming machine :Control :PLC
Weight:3T or so
Large Frame Material:300H stell
roll and wall roll forming machine :
The colored steel tile made by this roll forming machine has beautiful sppearance, it looks elegant and special, can be used in manufacture, beauty spot, pavilion, hotel, villa, exhibition hall, holiday village and ect. It has light material and high intensity, high wind resistance and waterproof function, high building efficiency with low cost.
Main technical parameters:
1. Passive leak: manual up tight, passive leak
2. Leak rack load: 4T
3. Rack: Using 300H steel welding
4. Forming Machine-driven feeding frame Type: Side roller
5. Forming Machine Type: wall-type chain drive
6. Shaft Diameter: 70 mm
7. Chain: 0.6-inch single-row
8. Forming Motor Power: 3KW Speed Reducer
9. Forming Machine speed: 8m/min
10. Forming Machine Road Number: 11
11. Roll Material: high quality forged steel
12. Hydraulic station motor: 3kw
13. Hydraulic Pump Station: Gear pump
14. Cutting method: hydraulic shear
15. Scissors film forming material: Cr12
16. Shearing blades Heat treatment: HRC58 ° -60 °
17. Rolling thickness :0.3-0 .8 mm
18. Material Expand Width: 1000mm/1200mm
19. Length Length Accuracy: ± 2mm
21. The computer use of PLC, Japan's panasonic
22. Computer Operator
We can provide almost all the types with different Coil width and Height of wave, we will supply the profile drawing as your inquiry.
Service: one-year warranty, responsible for commissioning,and we will provide the technical support for the whole life of the equipment
