Glazed Tile Building Material Making Machine Fro Color

Glazed Tile Building Material Making Machine Fro Color thumbnail-1
Glazed Tile Building Material Making Machine Fro Color photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Tile Forming Machine
Tile Type:
Colored Glaze
Use:
Wall
Contact Supplier Request Quote Chat Now
Botou Golden Integrity Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin new port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Tile Forming Machine
Tile Type Colored Glaze
Use Wall
Place of Origin Hebei, China
Brand Name JCX

Specifications

tile machine
European style design
Details improvement
CE and ISO certificate passed

roof tile machine  Main technical parameters:
1. Rack: Using 300H steel welding
2. Forming Machine-driven feeding frame forms: lateral slide-style
3. Forming Machine Type: wall-type chain drive. Wall thickness of 16 mm.
4. Shaft Diameter: 75 mm
5. Chains: 1 inch single-row
6. Forming Motor Power: 4KW
7. Forming Machine speed: 1.0m/min
8. Forming Machine Road Number: 12
9. Roll Material: high quality 45 # steel Duan playing pieces
10. Hydraulic station motor: 4kw °
11. Rolling thickness :0.3-1 .0 MM
12. Materials Expand Width: 1200mm
13. The computer use of PLC, Taiwan and Taiwan reached
14. The machine weighs about 4 tons, length of 7 meters wide and 1.45 meters, 1.2 meters high.
.The forming rollers are the key of roll forming machine. We use CAD to design and manufacture the rollers. After CNC lathe, the forming rollers will be harden by vacuum heat treatment and finished the profiles again. These processes make the more accurate forming rollers, avoid the deformation during heat treatment and ensure the rollers preciseness and wear-resisting ability.Glazed tile building material making machine fro colorGlazed tile building material making machine fro colorGlazed tile building material making machine fro color
