Help CenterAutomatic Floor Tile Making Machine for Color
Related Products
Specifications
making machineautomatic system
advanced technicians
superior auality
pass CE
making machine
main techinical specificatiom:
1. passive leak: manual up tight,passive leak
2. the bearing of decoiler: 5T
3. rack: the thickness of middle plate is 18 mm which adopting 350H steel welding
4. the form of forming machine-driven feeding frame: sidewise roller
5. forming machine shape: wall-type chain drive
6. shaft diameter: 72 mm solid shaft
7. chain: 0.6 inch single now
8. forming machine motor reducing qear drive
9. forming macine line speed: 1.5m/min
10. forming machine tracks number: 11 roller
11.roll material: bearing steel
12. roll heat treament : HRC58° -60
13. hydraulic station motor: 3kw
14. hydraulic oil pump: taiwan jinyong gear pump
15. cutting mathod: flying saw cut, mesopore is set freely
16. flying saw motor: 11kw
17. rolling thickness: 0.3-0.8mm
18. accuracy of fixing length: ± 2mm
19. the computer is adopted with PLC, Japen's panasonic
We also make the special size as the client's request !
