Machinery for Concrete Roof Tile

Machinery for Concrete Roof Tile thumbnail-1
Machinery for Concrete Roof Tile photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Tile Forming Machine
Tile Type:
Colored Steel
Use:
Roof
Contact Supplier Request Quote Chat Now
Botou Golden Integrity Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Tile Forming Machine
Tile Type Colored Steel
Use Roof
Place of Origin Hebei, China
Brand Name JCX

Specifications

concrete roof tile making machine 1. Nice appearence.
2. Low noise.
3. High efficiency.
4. Good quality.
5. Esay control

concrete roof tile making machine

1.1 Feeding width: 1000mm
1.2 Effective width: 910mm
1.3 Material thickness: 0.3-0.8mm

2. Process flow:

Decoiling--feeding---forming---cutting---production

3. Manual Decoiler:
3.1 Material coil inner diameter: 450mm-700mm
3.2 Max coil width: 1200mm
3.3 Carrying capacity: 5T

4. Forming Device:
4.1 Number of forming steps: 13 steps
4.2 Shaft material: 45# steel with harden treatment, outer diameter 75mm
4.3 Roller material: 45# steel
4.4 Main motor power: 3kw
4.5 Forming speed: 8-10m/min
4.6 Voltage: 380V/50Hz/3 phase

5. Cutting Device:
5.1 hydraulic cutter
5.2 blade, puncher and mold material: Cr12 steel with quenched treated 60-62C
5.3 cutting system: Advanced hydraulic drive, automatic cutting after forming, no distorting or wasting, high level safety factor.

6. Controlling Device:
6.1 screen: 5.7 inch Taida screen from Taiwan
6.2 PLC: Taida DVP14ES from Taiwan
6.3 coder: Japanese Omron E6C2

7. Hydraulic:
7.1 Advanced hydraulic system from Taiwan
7.2 Power: 3kw

8. Simple output frame: Simple frame weld bu #8 U bar, 1 PCS of 3m

Suitable to process Steel plate
Width of the plate 1000mm/1200mm/1250mm
Rollers 9-11rows
Dimensions 5.8*1.55*1.51m
Power 4kw+4kw
Thickness of the plate 0.3-0.7mm
Productivity  8-10m/min
Diameter of the roller ¢70mm
Weight About 3.4T
Voltage 380V  50Hz 3pha
machinery for concrete roof tilemachinery for concrete roof tile, machinery for concrete roof tilemachinery for concrete roof tile
