0.5-2.0nmm Thickness ,tension Leveling Machine, Sltting,Cut to Length Line for Steel Coils With High Precision

US$ 65,000 - 220,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

JCX

Botou Golden Integrity Roll Forming Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin xingang

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name JCX

Model Number JCX0.5-2.0nmm thickness

Voltage 220/380/410/440V

Rated Power 18.5+7.5KW

Dimension(L*W*H) 11mX1.3mX1.35m

Weight 10TON

Certification TUV

Warranty ONE YEAR

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Low cost can slove big problem
No need to buy high cost material any more

No.	Item	Description
1	Suitable material	Strip steel, GI, PPGI, AL
2	Working speed	0-50m/min not including punching and cutting
3	Main motor power	18.5kw with cycloidal reducer
4	Hydraulic station power	7.5kw
5	Electrical control system	PLC control system with famous brand
6	Thickness of material	0.5-2.0mm
7	Shaft diameter	80mm
8	Roller station	12stations
9	Material expand axis	200-600mm
10	Dimension	11mX1.3mX1.35m
11	Driving mode	Chain
12	Electric tension	380V 3phase 50HZ or as the customer's requirements
13	Material of roller	High grade 45# forged steel plated with hard chrome plating
14	Material of cutting	Cr12 mould steel with quenched treatment
15	Working time	Can be 24 hours
16	Workers	1-2 only
