Specifications
1) solid-liquid separation2) large diameter, for mass treatment
3) engineering guide installation
Shallow Water Air flotation machine
1. Pool diameter:
3M-14M, per your requirement.
2. Application: (water treatment project)
1) For water works, which use lake water as its water source.
(Remove the algae, meantime reduce the turbidity degree.)
2) For industrial sewage water treatment, like petrol, paper making industry, texile, printing, electroplate, leather, and food industry.
3) Recycle the valuable material of the sewage water, like fiber recovery from paper mil water and wood pulp water.
Technical parameter:
Model |
Diameter(mm) |
Height(mm) |
Capacity(m3/h) |
Power(KW) |
Separation zone area (m2) |
Working load(t) |
Air dissolved system power(KW) |
ZCQJ25 |
φ3000 |
1100 |
25 |
1.3 |
6 |
12 |
7 |
ZCQJ45 |
φ3000 |
1100 |
45 |
1.85 |
10 |
16.8 |
7 |
ZCQJ70 |
φ5000 |
1100 |
70 |
2.6 |
16 |
21.1 |
9 |
ZCQJ110 |
φ6000 |
1100 |
110 |
3.3 |
26 |
28 |
17 |
ZCQJ150 |
φ7000 |
1125 |
150 |
3.3 |
35 |
40 |
21 |
ZCQJ200 |
φ8000 |
1150 |
200 |
3.3 |
46.4 |
45 |
23.5 |
ZCQJ250 |
φ9000 |
1200 |
250 |
3.3 |
58 |
46 |
23.5 |
ZCQJ300 |
φ10000 |
1200 |
300 |
5.2 |
70 |
57 |
31.5 |
ZCQJ400 |
φ11000 |
1200 |
400 |
6.2 |
93 |
68 |
45 |
ZCQJ450 |
φ12000 |
1200 |
450 |
6.2 |
105 |
81 |
45 |
ZCQJ500 |
φ13000 |
1200 |
500 |
6.2 |
115 |
93 |
46.5 |
ZCQJ600 |
φ14000 |
1200 |
600 |
6.2 |
140 |
110 |
46.5 |
Need more solution? Contact with us:
Anna Miller/ export dept.
Mobile:86-15092424957/ 13606461467 (whats app)
Skype: anna.bettertech
Email: betterwater005(at)
QQ: 944623877
Shandong Better Enviromental Protection Technology Co.,ltd
Solution Advice, Installation &. Operation Guide.
You can provide us the water sources, water quality, flow rate and ground area, material requirements about your project, then more technical solutions will be suggested to you.
