45m Diameter Bridge Type Automatic Scrapping Machine

45m Diameter Bridge Type Automatic Scrapping Machine thumbnail-1
45m Diameter Bridge Type Automatic Scrapping Machine photo-1
US$ 3,900 - 28,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Better
Model Number:
ZBX
Contact Supplier Request Quote Chat Now
Shandong Better Environmental Protection Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Better
Model Number ZBX

Peripheral Drive Mud Scraper  (16-50m diameter)



Product Description

This equipment is peripheral drive. the sewage radial flows through the central pipe of  the pool the spreaded by the distrubutor tube then the suspended mud can deposite. the driving device can revolove with the working bridage the scraper arm and the board can move together at the same time. The scraper board gathers the mud together and the pipe discharges the mud into the central mud tank by the water pressure bearing in the pool. the mud releases outside of the pool through the mud pipes. the suspending fross floating leads to the dross hopper through the revolving device for scrape dross. the supernatant release through the outlet trough from the triangle outlet water weir.



1. Peripheral line speed: 1-2m/min

2. Pond diameter: 16-50m

3. Adviced pond depth: 3-4m

4. Gradient: 1:10

5. Technical data:

Model

Pond diameter(m)

Speed(m/min)

power(kw)



Pond depth(m)

Gradient







whole bridge

half bridge





ZBX-16

16

1-2

0.37*2

0.37

3-4

1:10

ZBX-20

20

1-2

0.55*2

0.55

3-4

1:10

ZBX-24

24

1-2

0.75*2

0.75

3-4

1:10

ZBX-30

30

1-2

0.75*2

0.75

3-4

1:10

ZBX-35

35

1-2

0.75*2

0.75

3-4

1:10

ZBX-40

40

1-2

1.1*2

1.1

3-4

1:10

ZBX-45

45

1-2

1.5*2

1.5

3-4

1:10

ZBX-50

50

1-2

1.5*2

1.5

3-4

1:10





Our Services

 Solution Advice, Installation and Operation Guide

Why choose us?

1)  Q: are you factory or trading company?

     A: We are Solid Factory, professional manufacture in sewage treatment plant;

                                                                                 solid waste incinerator;

                                                                                 solid and liquid separation.

2) Q: What kind of certificate you have?

    A: ISO9001:2008; SGS; CE avaible.



3) Q: Can you customize the machinery according to our specific requirement?

    A: Yes,we can make your ideal machinery.



4) Q: When am I supposed to receive the reply of my inquiry?

    A: We assure you that any of your inquiry will be replied within 12hours.



5) Q: Is engineers overseas available?

    A: Yes we can send our experienced engineer go abroad to guide with installation of the plant.





Hope above infos are helpful for you,   also you can send me your inquiry through below contact details:
