Specifications
1.Cavitation Air Floatation Machine For Water Purifying2.saving energy
3.low cost
4.high efficiency
5.easy to operate
Cavitation Air Floatation Machine For Water Purifying
1.Description:
It is used to remove impurities such as solid suspended particles, grease and jelly etc. SS and COD can be eliminated to the greatest extent under the help of chemical flocculant. This machine is applicable for white water and middle-stage wastewater treatment of paper mill. With fiber recovery and reuse of water after treatment helps release environmental pressure. Designed according to popular style of USA, it features advanced technology, simple structure and easy maintenance.
2. Technical parameter:
Model |
Capacity (m3/h) |
Power (KW) |
L(m) |
W(m) |
H(m) |
ZCAF-5 |
5 |
3.3 |
2.44 |
0.93 |
1.26 |
ZCAF-10 |
10 |
3.3 |
3.05 |
1.23 |
1.26 |
ZCAF-15 |
15 |
3.3 |
3.96 |
1.23 |
1.26 |
ZCAF-20 |
20 |
3.3 |
4.57 |
1.23 |
1.26 |
ZCAF-25 |
25 |
3.3 |
5.00 |
1.50 |
1.26 |
ZCAF-30 |
30 |
3.3 |
5.50 |
1.52 |
1.26 |
ZCAF-35 |
35 |
3.3 |
6.00 |
1.52 |
1.26 |
ZCAF-50 |
50 |
3.3 |
5.33 |
1.80 |
1.83 |
ZCAF-75 |
75 |
3.3 |
6.55 |
2.41 |
1.83 |
ZCAF-100 |
100 |
5.5 |
7.71 |
2.41 |
1.83 |
ZCAF-150 |
150 |
6.6 |
11.13 |
2.41 |
1.83 |
ZCAF-175 |
175 |
8.8 |
12.95 |
2.41 |
1.83 |
ZCAF-200 |
200 |
8.8 |
15.09 |
2.41 |
1.83 |
ZCAF-320 |
320 |
11 |
15.09 |
3.05 |
1.83 |
ZCAF-400 |
400 |
13.2 |
16.60 |
3.05 |
1.83 |
ZCAF-500 |
500 |
15.4 |
20.60 |
4.05 |
1.83 |
