New technology china 4 spindle ATC wood cutting machine
Applicable:
cabinet door, solid wood doors, computer desk, board type furniture, etc;Can be used in large area, big output high density board, solid wood plane engraving, cutting, such as 3 d relief operation.The machine for diversified complexity processing models, suitable for wenqi door, the door of the lacquer that bake, board type furniture, such as complicated technology, modelling more products to mass production.
Feature:
The new four pneumatic tool change woodworking engraving machine More accurate, more intelligent, more humane, more and more durable!
High efficiency: transmission speed: fast carving: smooth operation, intelligent control, high precision, strong and durable:
The original dimension of macro control, support U disk operation: humanized design, unique mechanical design:
Technical Parameter:
Model |
BDX-2030 |
XYZ-axis travel |
2000*3000*200mm |
Guide Rail |
HIWIN linear guide rail |
Max. speed |
2800mm/min |
Max. engraving speed |
2000mm/min |
Max. feeding height |
200mm feed |
Resolution |
0.005mm |
Repeated positioning accuracy |
0.05mm |
Command |
G code. U00. Mmg. Plt. Eng |
Software operating environment |
WIN2000/XP |
Voltage |
380V/220V/110V |
Spindle power |
3.5KW*2+5.5KW*2 |
Spindle speed |
0-24000rpm/min |
Stepper motor |
Stepper motor / Servo motor (optional) |
Package size |
3170 * 2110 * 1700mm |
Control system |
Nctudio/DSP(Optional) |
Weight |
1440kg |
Optional accessories |
Cylinder rotary attachment/ Dust collecter/ Metal water tank/Vacuum adsorption system |
1.”Guarantee & After-Sales Service |
1.1“One year warranty under normal use and we supply maintenance for life for free. |
1.2“24 hours technical support by phone, e-mail, SKYPE, MSN or Remote. |
1.3“Free trainings to make sure you master the operation of cnc router. |
1.4“English operation manual, popular and easy to understand. |
2.”OEM Service Available |
2.1“Usually, we will manufacture the machine as our regular design. |
2.2“X Y Z Working Area could be customized designing. |
2.3“Special configuration could be customized designing. |
3.’Delivery Time (Production procedure) |
3.1“For 3 axis machine with standard specification, usually 15 days. |
3.2“For 4 axis machine with standard specification, usually 30 days. |
3.3“For 5 axis machine, OEM or non-standard models, usually 45 days. |
4.”Payment Terms” |
4.1“T/T in advance. |
|
4.2“Western union: we can accept small payment (below $3000), but the banking charges shall be paid by the buyer. |
4.3“L/C is acceptable if the amount is big. Please issue the L/C draft for our confirmation first. |
Thank you for your time ! What can I do for you ? :)
