Servo Motor Injection Moulding Machine

Dongguan Zan Yi Machinery Technology Co., Ltd.
Servo Motor Injection Moulding Machine thumbnail-1
Servo Motor Injection Moulding Machine photo-1
US$ 8,000 - 8,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, screw injection
Style:
Vertical
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, screw injection
Style Vertical
Brand Name ZAN YI
Model Number ZY-350ST-DM-SS
Place of Origin Guangdong, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 74g,84g,106g
Injection Rate 81cm3/sec,92cm3/sec,110cm3/sec
Clamping Force 45T
Opening Stroke 200mm
Power(W) 18KW
Certification CE,ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

servo motor injection moulding machine

Product Details:

Item Name:  small sized plastic injection molding machine

 Specifications:
MODELUNITZY-350ST-DM-SS
Screw DiameterMm303235
Injection Pressurekg/cm²1171996810
Theoretical Shot Volumecm³8192117
Max.Shot Weight(ps)g7484106
Safe Shot Weight(ps)OZ2.633.8
Max.Shot Weight(ps)cm³/sec62.57195
Injection Ratemm115
Screw Speed Max.rpm0-190
Nozzle Comtact ForceTons4.45
Nozzle Retraction Strokemm190
Number of Temperature Control 3
Clamping ForceTons45
Platen Sizemm830*400
Min.Mold Heightmm200/150
Opening Strokemm200
Max.Open Daylightmm450/350
Ejetor ForceTons1.5
Ejetor Stokemm135
Max.Hydaulic Pressurekg/cm²140
Pump Outputl/min37.2×2
Oil Resservoir Capacityl180
Cooling Waer Consumptionl/hr600-800
Pump Motor PowerKW/HP5.5/7.5P×2
Berrel Heating PowerKW2.8×2
Total  ElectricityKW18
Machine WeightTons4.2
Machine Dimensions(LxWxH)m2.5*1.9*3.08
Shipping WeightTons4.5
Shipping Measurements(LxWxH)m2.6*2*2.3

 Features:

1.Load double-mode aiternnated slide board in CY-DM double-color machine .One slow die and two upper dies are loaded in the machine .Alternate the dies from left to right at the same flat surface.After the completing of one color,do not take out the products but change the slide board to the second color to efficiency can be advanced in a large range.The finished goods are propped up to outside for completion.
2.Two single machines can be operated independently.Two machines can be also connected to operate.
3.When use single machine ,thimble is built in.
4.Phase 5 of screw single machine controls temperature.
5.Material tube can be lifted .It is easy to clean stub bar .It is easy to fix die.
6.Low-pressure closed die assembly can protect the safety of die.

Samples produced:

servo motor injection moulding machine
