Injection Molding Machine

Injection Molding Machine thumbnail-1
Injection Molding Machine photo-1
US$ 8,000 - 8,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, screw injection
Style:
Vertical
Contact Supplier Request Quote Chat Now
Dongguan Zan Yi Machinery Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, screw injection
Style Vertical
Brand Name ZAN YI
Model Number ZY-2000SWT
Place of Origin Guangdong, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 432g,514g,700g
Injection Rate 107cm3/sec,128cm3/sec,174cm3/sec
Clamping Force 200T
Opening Stroke 360mm
Power(W) 32KW
Certification CE,ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

injection molding machine

Product Details:

Item Name:  medical injection machine

 Specifications:
MODEL UNIT ZY-2000SWT
Screw Diameter Mm 55 60 70
Injection Pressure kg/cm² 2036 1711 1257
Theoretical Shot Volume cm³ 475 565 770
Max.Shot Weight(ps) g 432 514 700
Safe Shot Weight(ps) OZ 15 18 24.5
Max.Shot Weight(ps) cm³/sec 107 128 174
Injection Rate mm 200
Screw Speed Max. rpm 0-200
Nozzle Comtact Force Tons 4.3
Nozzle Retraction Stroke mm 400
Number of Temperature Control   4
Clamping Force Tons 200
Platen Size mm 1080*900
Min.Mold Height mm 250/350
Opening Stroke mm 360
Max.Open Daylight mm 610/710
Ejetor Force Tons 5.6
Ejetor Stoke mm 150
Max.Hydaulic Pressure kg/cm² 140
Pump Output l/min 94
Oil Resservoir Capacity l 300
Cooling Waer Consumption l/hr 1200-1500
Pump Motor Power KW/HP 22.5/30HP
Berrel Heating Power KW 8.5
Total  Electricity KW 32

 Features:

1.Straight scew ejected assembly.

 2.Two(three) phase temperature ,ejected speed,backing pressure and screw speed is

suitable for various plastic to confectioned.

3.Low-die fixed top active mode makes inserted objects excellent positioned features and the machine has liftout attachment for finished goods.

4.Low-pressure closed die assembly can protect the safety of die .

5.Material tube can be lifted ,It is easy to clean stub bar .It is easy to fix die .

6.Can be installed a single mold or double shuttle table.

Samples produced:

injection molding machine
