water heating injection mold temperature controller
| Model | TCH-56B/W |
| Cooling Power | 3.7kw |
| Pump power | 0.75KW |
| Chilled Flow | 110L/MIn |
| Chilled ID | 3/8"*4PT |
| Heating Power | 0.37kw |
| Hot water Flow | 40L/MIn |
| Hot water ID | 3/8"*2 PT |
| Size | 950*600*950mm |
| Weight | 120KG |
Safety System :
1.Electric Power's lack-phase & anti-phase Protactor and its Signal Light
2.Master Electric Leakage Switch
3. Punch's Rolling Back Protector and its Signal Light.
4. Compressor's Rolling Back Protector and its Signal Light
5.Punch 's Overload Protector and its Signal Light
6.Compressor's Overload Protector and its Signal Light
7. Chiller's High Voltage Protector and its Signal Light.
8. Compressor's Low Voltage Protector and its Signal Light
9.Compressor's Anti-ice Protector.
10.Compressor's Timedelay Start Safeguard.
11. Ultra-temperature Heating Protector
12.Tube Overload Heating Protector.
Features:
1.Have to make mold with heat the dual function, and can satisfy any product to request molding tool.
2.The high Precision Configuration, volume is small, be applicable to the high Precision Injection.
3.The adoption imports the thermometer, It can control the temperature deviation accurately within ±1℃.
4.Humanized operate system, when bread down the occurrence immediately show the breakdown reason
5.Design of easy disassambly type, wash with maintain more convenient
