The expanded plate mesh machine produced by our company is high technology, and high practicability, It can produce steel plate mesh, aluminum plate mesh, titanium plate mesh and some other material mesh.
The machines are used for punching all kinds of expand plate mesh in construction, common hardware, window and door, machine protecting etc.
Feeding mechanism passes the chain link by the main engine directly, the movement accurate is reliable.
Type |
JQ25-6.3 |
JQ25-16 |
JQ25-25 |
JQ25-63 |
JQ25-125 |
Pounding thickness |
≤1.0mm |
≤1.2mm |
≤1.5mm |
≤2.5mm |
≤6mm |
Pounding width |
≤500mm |
≤1000mm |
≤1250mm |
≤2000mm |
≤2500mm |
Stocks per minute |
230/min |
160/min |
130/min |
70/min |
40/min |
Distance of feeding |
0-1.15mm |
0-1.2mm |
0-1.2mm |
0-4mm |
0-7mm |
Length of the mesh |
≤20mm |
≤25mm |
≤30mm |
≤100mm |
≤250mm |
Press plate pressure |
63KN |
160KN |
250KN |
630KN |
1250KN |
power |
2.2KW |
3KW |
4KW |
11KW |
22KW |
Overall weight |
1.2T |
2.5T |
3T |
10T |
18T |
|
Outside size (L*W*H)mm |
1090 *710 *1450 |
1800 *1400 *1870 |
1740 *1400 *2010 |
3560 *3500 *2300 |
5800 *3270 *1925 |
The Warranty
1.Reply you enquiry in 24 hours working hours
2.Experienced staffs answer all your questions about the machine
3.Exclusive and unique solution can be provided to our customer by your well-trained and professional engineer.
4.Special discount and protection of sale area provided to your distributor.
5.Engineer can install,test and adjust the machine for you when the machine arrived your factory 7days.
6.Engineer can repair machine to your factory
7.Guarantee: one year, some accessories free for you.
Payment Terms
1. 30% T/T in advance, 70% payable against the copy of the B/L.
2. L/C is also acceptable.
3. As per your special requirement, we can discuss it.
