Pantalla de LED gigante full color para publicidades exteriores giant tv led p10
Outdoor SMD Fixed box LED Display:
1.with multi- functional card, it can turn on and turn off the screen by timing or manually at any time.
2.with sensor card, it can adjust screen brightness automatically according to the
changing light between day and night which can save energy to reduce your operating cost greatly
In addition, it can prolong the lifespan of the LED Display.
3.High refresh rate and high gray make the picture vivid which meets the demand of
high visual quality of commercial usage.
Outdoor LED Display applications:
---Outdoor advertising, digital billboards, advertising in big companies
---Sports halls, fields, playgrounds.
---Airports, bus stations and railway passenger terminals.
---Facades of shopping malls, department stores, banks and car dealerships.
---Architecture and social projects, information systems in cities.
---Show-business, concerts, festivals, motor shows and other public events.
Outdoor SMD LED screen technical specs:
| Outdoor SMD Fixed Installed Advertising Media LED Displays | |||
| Module | Pitch/mm | P8 | P10 |
| Module size/mm | 256x256 | 160x160 | |
| Density of pixel/(dots/m2) | 15625dots | 10000dots | |
| Pixel composition | 1R1G1B | 1R1G1B | |
| Led encapsulation | SMD3535 | SMD3535 | |
| Resolution of module | 32*32 | 16*16 | |
| Main | Optimum viewing distance | 8-100m | 10-150m |
| View angle / ° | 140H,120V | 140H,140V | |
| Max power consumption/W/M2 | 750w | 750w | |
| Size of cabinet/mm | 1024X1024 | 960X960 | |
| Resolution of cabinet | 128*128 | 96*96 | |
| Driving method | 1/4 scan constant current | 1/4 scan constant current | |
| Refresh rate Hz/S | ≥1200 | ≥1200 | |
| Luminance of white balance | ≥7000 nits | ≥6000 nits | |
| Operation of Environmental Temperature/℃ | below 30 to above 50 | ||
| IP rating | IP65 | ||
| Working voltage | 110-220 VAC/+/- 10% | ||
| Grey scale/color | displaying colors≥16.7M(synchronized) | ||
| Brightness adjustment | 4096 levels of each color(manually),100 levels of each color(automatically) | ||
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc | ||
| Control system | Linsn / Nova(sending card, receiving cards and Hubs) | ||
| Average of non-failure life | >50,00h | ||
| Life span | >100,000h | ||
| Functionless dot rate | <0.0001 | ||
Outdoor LED panel for advertising:
| Front access easy maintenence | double side led screen outdoor |
|
|
|
|
| football, sports stadium led display outdoor | |
|
|
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time.
Warmly welcome to visit our factory in shenzhen,china.
